625-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
625 SERIES RIGHT ANGLE D-SUB PLU
| Part | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Color | Number of Positions | Contact Type | Termination | Current Rating (Amps) | Flange Feature | Number of Rows [custom] | Mounting Type | Connector Type | Connector Style | Backset Spacing | Backset Spacing | Contact Finish | Features | Contact Finish Thickness | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Material Flammability Rating | Shell Material, Finish | Flange Feature | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | 4-40 Mating Side Female Screwlock | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Flash | B DB | 3 | UL94 V-0 | Nickel Plated Steel | |||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | Housing/Shell | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Flash | B DB | 3 | UL94 V-0 | Nickel Plated Steel | 4-40 | ||
 EDAC Inc. | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | 4-40 | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | B DB | 3 | UL94 V-0 | Nickel Plated Steel | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | Housing/Shell (M3) | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | B DB | 3 | UL94 V-0 | Nickel Plated Steel | 15 µin | 0.38 µm | ||
 EDAC Inc. | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | 4-40 Mating Side Female Screwlock | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Flash | B DB | 3 | UL94 V-0 | Nickel Plated Steel | |||
 EDAC Inc. | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | 4-40 Mating Side Female Screwlock | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | B DB | 3 | UL94 V-0 | Nickel Plated Steel | 15 µin | 0.38 µm | ||
 EDAC Inc. | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | 4-40 Mating Side Female Screwlock | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | Flash | B DB | 3 | UL94 V-0 | Nickel Plated Steel | |||
 EDAC Inc. | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | Housing/Shell | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | B DB | 3 | UL94 V-0 | Nickel Plated Steel | 4-40 | 30 Áin | 0.76 Ám | |
 EDAC Inc. | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | Housing/Shell (Unthreaded) | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Grounding Indents Mounting Brackets Shielded | B DB | 3 | UL94 V-0 | Nickel Plated Steel | 15 µin | 0.38 µm | ||
 EDAC Inc. | Copper Alloy | -55 C | 85 °C | Polyester Thermoplastic | Black | 25 | Signal | Solder | 3 A | 4-40 | 2 | Board Edge Right Angle Through Hole | Plug Male Pins | D-Sub | 0.584 " | 14.84 mm | Gold | Board Lock Grounding Indents Mounting Brackets Shielded | B DB | 3 | UL94 V-0 | Nickel Plated Steel | 15 µin | 0.38 µm |
