AWHW-254-10 Series
Manufacturer: Assmann WSW Components
Beta
⌘K
DIN 41651
| Part | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Mounting Type | Insulation Height [z] | Insulation Height [z] | Current Rating (Amps) | Number of Positions Loaded | Contact Material | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Connector Type | Contact Shape | Termination | Number of Rows [custom] | Shrouding | Contact Length - Post [x] | Contact Length - Post [x] | Insulation Color | Number of Positions | Insulation Material | Contact Finish Thickness - Mating | Material Flammability Rating | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Length - Mating | Contact Length - Mating | Contact Type | Style | Features | Insulation Height | Insulation Height | Contact Finish - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Assmann WSW Components | 0.1 in | 2.54 mm | Right Angle Through Hole | 0.427 in | 10.85 mm | 3 A | All | Brass | Gold | 0.1 " | 2.54 mm | Header | Square | Solder | 2 | Shrouded - 4 Wall | 0.126 " | 3.2 mm | Black | 10 | Glass Filled Nylon 9T Polyamide (PA9T) | Flash | UL94 V-0 | Latch Lock/Eject Hooks | -40 C | 105 ░C | 6 mm | 0.236 in | Male Pin | Board to Cable/Wire | ||||
Assmann WSW Components | ||||||||||||||||||||||||||||||||||
 Assmann WSW Components | 0.1 in | 2.54 mm | Surface Mount | 0.87 " | 22.1 mm | All | Brass | Gold | 0.1 " | 2.54 mm | Header | Square | Solder | 2 | Shrouded - 4 Wall | Black | 10 | Glass Filled Nylon 9T Polyamide (PA9T) | Flash | UL94 V-0 | Latch Lock/Eject Hooks Long | -40 C | 105 ░C | 6 mm | 0.236 in | Male Pin | Board to Cable/Wire | Keying Slot | ||||||
 Assmann WSW Components | 0.1 in | 2.54 mm | Surface Mount | All | Brass | Gold | 0.1 " | 2.54 mm | Header | Square | Solder | 2 | Shrouded - 4 Wall | Black | 10 | Glass Filled Nylon 9T Polyamide (PA9T) | Flash | UL94 V-0 | Latch Lock/Eject Hooks | -40 C | 105 ░C | 6 mm | 0.236 in | Male Pin | Board to Cable/Wire | Keying Slot | 0.736 in | 18.69 mm | ||||||
 Assmann WSW Components | 0.1 in | 2.54 mm | Through Hole | 0.87 " | 22.1 mm | 3 A | All | Brass | Gold | 0.1 " | 2.54 mm | Header | Square | Solder | 2 | Shrouded - 4 Wall | 0.126 " | 3.2 mm | Black | 10 | Glass Filled Nylon 9T Polyamide (PA9T) | Flash | UL94 V-0 | Latch Lock/Eject Hooks Long | -40 C | 105 ░C | 6 mm | 0.236 in | Male Pin | Board to Cable/Wire | Tin | |||
Assmann WSW Components | 0.1 in | 2.54 mm | Right Angle Through Hole | 0.427 in | 10.85 mm | 3 A | All | Brass | Gold | 0.1 " | 2.54 mm | Header | Square | Solder | 2 | Shrouded - 4 Wall | 0.126 " | 3.2 mm | Black | 10 | Glass Filled Nylon 9T Polyamide (PA9T) | Flash | UL94 V-0 | Latch Lock/Eject Hooks | -40 C | 105 ░C | 6 mm | 0.236 in | Male Pin | Board to Cable/Wire | Keying Slot | |||
Assmann WSW Components | 0.1 in | 2.54 mm | Through Hole | 0.87 " | 22.1 mm | 3 A | All | Brass | Gold | 0.1 " | 2.54 mm | Header | Square | Solder | 2 | Shrouded - 4 Wall | 0.126 " | 3.2 mm | Black | 10 | Glass Filled Nylon 9T Polyamide (PA9T) | Flash | UL94 V-0 | Latch Lock/Eject Hooks | -40 C | 105 ░C | 6 mm | 0.236 in | Male Pin | Board to Cable/Wire | Polarizing Key |
