392-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 29POS 0.100
| Part | Material - Insulation | Termination Rows | Termination | Number of Positions | Pitch | Pitch | Gender | Read Out | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Number of Positions/Bay/Row | Contact Type | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Black | 29 | Cantilever | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Wire Wrap | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Black | 29 | Cantilever | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder Wire Wrap | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Black | 29 | Cantilever | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Black | 29 | Cantilever | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Wire Wrap | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Black | 29 | Cantilever | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder Wire Wrap | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Black | 29 | Cantilever | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | 29 | Cantilever | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Wire Wrap | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Black | 29 | Cantilever | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Wire Wrap | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Black | 29 | Cantilever | Gold |
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | 29 | 0.1 " | 2.54 mm | Female | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 1 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Black | 29 | Cantilever | Gold |
