82A1A Series
Manufacturer: Bourns Inc.
Beta
⌘K
POT 50K OHM 1/2W PLASTIC LOG
| Part | Adjustment Type | Built in Switch | Termination Style | Number of Gangs | Size - Body [y] | Size - Body [y] | Size - Body [x] | Size - Body [x] | Resistive Material | Temperature Coefficient | Number of Turns | Resistance (Ohms) [custom] | Rotation | Actuator Type | Actuator Length [x] | Actuator Length [x] | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Tolerance | Mounting Type | Bushing Thread | Taper | Power (Watts) | Power (Watts) | Resistance (Ohms) | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | User Defined | None | Solder Hook | 1 | 0.625 " | 15.88 mm | 0.625 " | 15.88 mm | Conductive Plastic | 1000 ppm/°C | 1 | 50 kOhms | 300 ░ | Slotted | 19.05 mm | 0.75 in | 6.35 mm | 0.25 in | 20 % | Panel Mount | 3/8-32 | Logarithmic | 0.5 W | 0.5 W | ||
 Bourns Inc. | User Defined | None | Solder Hook | 1 | 0.625 " | 15.88 mm | 0.625 " | 15.88 mm | Cermet | 150 ppm/°C | 1 | 300 ░ | Slotted | 19.05 mm | 0.75 in | 6.35 mm | 0.25 in | 10 % | Panel Mount | 3/8-32 | Linear | 2 W | 1k | |||
 Bourns Inc. | User Defined | None | Solder Hook | 1 | 0.625 " | 15.88 mm | 0.625 " | 15.88 mm | Cermet | 150 ppm/°C | 1 | 300 ░ | Slotted | 22.23 mm | 0.875 in | 6.35 mm | 0.25 in | 10 % | Panel Mount | 3/8-32 | Linear | 2 W | 1k | |||
Bourns Inc. | User Defined | None | Solder Hook | 1 | 0.625 " | 15.88 mm | 0.625 " | 15.88 mm | Conductive Plastic | 1000 ppm/°C | 1 | 300 ░ | Slotted | 22.23 mm | 0.875 in | 6.35 mm | 0.25 in | 20 % | Panel Mount | 3/8-32 | Logarithmic | 0.5 W | 0.5 W | 10k | ||
Bourns Inc. | User Defined | None | Solder Hook | 1 | 0.625 " | 15.88 mm | 0.625 " | 15.88 mm | Cermet | 150 ppm/°C | 1 | 300 ░ | Slotted | 22.23 mm | 0.875 in | 6.35 mm | 0.25 in | 10 % | Panel Mount | 3/8-32 | Linear | 2 W | 5 kOhms |
