AM3505 Series

Catalog

IC MPU SITARA 600MHZ 484BGA

Part	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - I/O	Security Features	Package / Case	Supplier Device Package	RAM Controllers	USB	Number of Cores/Bus Width	Display & Interface Controllers	Ethernet	Ethernet [Max]	Ethernet [Min]	Additional Interfaces	Speed	Co-Processors/DSP	Core Processor	Mounting Type	Operating Temperature [custom]
Texas Instruments AM3505AZERC	0 °C	90 °C	1.8 V 3.3 V	Cryptography	484-BBGA Exposed Pad	484-BGA (23x23)	DDR2 LPDDR	USB 2.0 (3) USB 2.0 + PHY (1)	1 Core 32 Bit	LCD	1	100 Mbps	10 Mbps	CAN HDQ/1-Wire I2C McBSP McSPI MMC/SD/SDIO UART	600 MHz	Multimedia NEON™ SIMD	ARM® Cortex®-A8	Surface Mount
Texas Instruments AM3505AZER	0 °C	90 °C	1.8 V 3.3 V		484-BBGA Exposed Pad	484-BGA (23x23)	DDR2 LPDDR	USB 2.0 (3) USB 2.0 + PHY (1)	1 Core 32 Bit	LCD	1	100 Mbps	10 Mbps	CAN HDQ/1-Wire I2C McBSP McSPI MMC/SD/SDIO UART	600 MHz	Multimedia NEON™ SIMD	ARM® Cortex®-A8	Surface Mount
Texas Instruments AM3505AZCNC	0 °C	90 °C	1.8 V 3.3 V	Cryptography	491-LFBGA	491-NFBGA (17x17)	DDR2 LPDDR	USB 2.0 (3) USB 2.0 + PHY (1)	1 Core 32 Bit	LCD	1	100 Mbps	10 Mbps	CAN HDQ/1-Wire I2C McBSP McSPI MMC/SD/SDIO UART	600 MHz	Multimedia NEON™ SIMD	ARM® Cortex®-A8	Surface Mount
Texas Instruments AM3505AZERA			1.8 V 3.3 V		484-BBGA Exposed Pad	484-BGA (23x23)	DDR2 LPDDR	USB 2.0 (3) USB 2.0 + PHY (1)	1 Core 32 Bit	LCD	1	100 Mbps	10 Mbps	CAN HDQ/1-Wire I2C McBSP McSPI MMC/SD/SDIO UART	600 MHz	Multimedia NEON™ SIMD	ARM® Cortex®-A8	Surface Mount	-40 °C 105 °C
Texas Instruments AM3505AZERAC			1.8 V 3.3 V	Cryptography	484-BBGA Exposed Pad	484-BGA (23x23)	DDR2 LPDDR	USB 2.0 (3) USB 2.0 + PHY (1)	1 Core 32 Bit	LCD	1	100 Mbps	10 Mbps	CAN HDQ/1-Wire I2C McBSP McSPI MMC/SD/SDIO UART	600 MHz	Multimedia NEON™ SIMD	ARM® Cortex®-A8	Surface Mount	-40 °C 105 °C
