HLW27R Series

Catalog

CONN FFC FPC TOP 27POS 1MM R/A

Part	Housing Color	Actuator Color	Mating Cycles	Housing Material	Number of Positions	Height Above Board [z]	Height Above Board [z]	Flat Flex Type	FFC, FCB Thickness	Features	Cable End Type	Contact Material	Operating Temperature [Min]	Operating Temperature [Max]	Connector/Contact Type	Voltage Rating	Mounting Type	Pitch	Pitch	Contact Finish	Termination	Material Flammability Rating
Amphenol ICC (FCI) HLW27R-2C7LF	Black	Black	30	Polybutylene Terephthalate (PBT) Glass Filled	27	0.154 in	3.9 mm	FFC FPC	0.3 mm	Solder Retention	Tapered	Phosphor Bronze	-55 C	85 °C	Contacts Top	100 V	Right Angle Through Hole	1 mm	0.039 in	Tin	Solder	UL94 V-0
