DS1500 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC RTC CLK/CALENDAR PAR 32EDIP

Part	Mounting Type	Current - Timekeeping (Max)	Package / Case	Package / Case	Package / Case	Features	Type	Supplier Device Package	Date Format	Operating Temperature [Max]	Operating Temperature [Min]	Time Format	Memory Size	Voltage - Supply, Battery [Max]	Voltage - Supply, Battery [Min]	Voltage - Supply [Max]	Voltage - Supply [Min]	Interface
Analog Devices Inc./Maxim Integrated DS1500Y	Through Hole	5 mA	32-DIP Module	15.24 mm	0.6 in	Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-EDIP	YY-MM-DD-dd	70 °C	0 °C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	5.5 V	4.5 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500YE+	Surface Mount	5 mA	32-LFSOP (0.724	18.4 mm		Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-TSOP	YY-MM-DD-dd	70 °C	0 °C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	5.5 V	4.5 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500WE+	Surface Mount	4 mA	32-LFSOP (0.724	18.4 mm		Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-TSOP	YY-MM-DD-dd	70 °C	0 °C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	3.6 V	3 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500YEN+	Surface Mount	5 mA	32-LFSOP (0.724	18.4 mm		Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-TSOP	YY-MM-DD-dd	85 °C	-40 C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	5.5 V	4.5 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500WN	Through Hole	4 mA	32-DIP Module	15.24 mm	0.6 in	Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-EDIP	YY-MM-DD-dd	85 °C	-40 C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	3.6 V	3 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500WEN	Surface Mount	4 mA	32-LFSOP (0.724	18.4 mm		Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-TSOP	YY-MM-DD-dd	85 °C	-40 C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	3.6 V	3 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500W	Through Hole	4 mA	32-DIP Module	15.24 mm	0.6 in	Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-EDIP	YY-MM-DD-dd	70 °C	0 °C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	3.6 V	3 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500YE	Surface Mount	5 mA	32-LFSOP (0.724	18.4 mm		Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-TSOP	YY-MM-DD-dd	70 °C	0 °C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	5.5 V	4.5 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500WEN+	Surface Mount	4 mA	32-LFSOP (0.724	18.4 mm		Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-TSOP	YY-MM-DD-dd	85 °C	-40 C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	3.6 V	3 V	Parallel
Analog Devices Inc./Maxim Integrated DS1500YEN	Surface Mount	5 mA	32-LFSOP (0.724	18.4 mm		Alarm Leap Year NVSRAM Square Wave Output Watchdog Timer Y2K	Clock/Calendar	32-TSOP	YY-MM-DD-dd	85 °C	-40 C	HH:MM:SS (24 hr)	256 B	3.7 V	2.5 V	5.5 V	4.5 V	Parallel
