DCCM21 Series

Manufacturer: Cinch Connectivity Solutions

Catalog

CABLE ASSY D-MIC-D 21P 457.2MM

Part	2nd Connector	1st Connector	Type	Number of Positions	Contact Finish Thickness	Contact Finish Thickness	Contact Finish	Color	Length [x]	Length [x]	Contact Material	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Shell Size, Connector Layout [y]	Shell Size, Connector Layout [x]	Flange Feature	Contact Type	Number of Rows [custom]	Material Flammability Rating	Termination	Current Rating (Amps)	Features	Shell Material, Finish	Connector Type	Connector Style	Backset Spacing	Backset Spacing	Length	Length
Cinch Connectivity Solutions DCCM21P6E5-18.0B	Individual Wire Leads	Male Pins Plug	D-Type Micro-D	21	50 µin	1.27 µm	Gold	Individual Multiple	457.2 mm	1.5 ft
Cinch Connectivity Solutions DCCM21SBSPN				21	50 µin	1.27 µm	Gold				Copper Alloy	Diallyl Phthalate (DAP) Glass Filled	-55 C	135 °C	Through Hole	0.043 in	0.05 in	Female Screwlock Mating Side	Signal	2	UL94 V-0	Solder	3 A	Shielded	Aluminum Alloy Electroless Nickel Plated	Receptacle Female Sockets	D-Type Micro-D
Cinch Connectivity Solutions DCCM21PCBRP				21	50 µin	1.27 µm	Gold				Copper Alloy	Diallyl Phthalate (DAP) Glass Filled	-55 C	135 °C	Right Angle Through Hole	0.043 in	0.05 in	Female Screwlock Mating Side	Signal	2	UL94 V-0	Solder	3 A	Shielded	Aluminum Alloy Yellow Chromate Plated Cadmium	Plug Male Pins	D-Type Micro-D	0.13 in	3.3 mm
Cinch Connectivity Solutions DCCM21PBSP				21	50 µin	1.27 µm	Gold				Copper Alloy	Diallyl Phthalate (DAP) Glass Filled	-55 C	135 °C	Through Hole	0.043 in	0.05 in	Female Screwlock Mating Side	Signal	2	UL94 V-0	Solder	3 A	Shielded	Aluminum Alloy Yellow Chromate Plated Cadmium	Plug Male Pins	D-Type Micro-D
Cinch Connectivity Solutions DCCM21P6E5-36.0BN	Individual Wire Leads	Male Pins Plug	D-Type Micro-D	21	50 µin	1.27 µm	Gold	Individual Multiple																						91.44 cm	3 ft
Cinch Connectivity Solutions DCCM21PBSPN				21	50 µin	1.27 µm	Gold				Copper Alloy	Diallyl Phthalate (DAP) Glass Filled	-55 C	135 °C	Through Hole	0.043 in	0.05 in	Female Screwlock Mating Side	Signal	2	UL94 V-0	Solder	3 A	Shielded	Aluminum Alloy Electroless Nickel Plated	Plug Male Pins	D-Type Micro-D
