871-43 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RCPT 9POS 0.07 GOLD PCB R/A

Part	Insulation Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Material	Contact Shape	Contact Finish - Post	Insulation Color	Contact Finish - Mating	Connector Type	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions Loaded	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Current Rating (Amps)	Contact Length - Post [x]	Contact Length - Post [x]	Mounting Type	Termination	Insulation Height [x]	Insulation Height [x]	Number of Rows	Material Flammability Rating	Number of Positions	Contact Type
Mill-Max Manufacturing Corp. 871-43-009-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	9	Female Socket
Mill-Max Manufacturing Corp. 871-43-013-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	13	Female Socket
Mill-Max Manufacturing Corp. 871-43-008-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	8	Female Socket
Mill-Max Manufacturing Corp. 871-43-020-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	20	Female Socket
Mill-Max Manufacturing Corp. 871-43-012-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	12	Female Socket
Mill-Max Manufacturing Corp. 871-43-011-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	11	Female Socket
Mill-Max Manufacturing Corp. 871-43-016-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	16	Female Socket
Mill-Max Manufacturing Corp. 871-43-021-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	21	Female Socket
Mill-Max Manufacturing Corp. 871-43-010-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	200 µin	5.08 µm	Beryllium Copper	Circular	Tin	Black	Gold	Receptacle	Push-Pull	-55 C	125 °C	All	0.76 Ám	30 Áin	0.07 in	1.78 mm	3 A	0.122 in	3.1 mm	Right Angle Through Hole	Solder	0.104 in	2.64 mm	1	UL94 V-0	10	Female Socket
