LUG TERMINAL, 90°, PAN-LUG LCA-F SERIES, CRIMP, 2 AWG, COMPRESSION LUG, M8

Part	Tab Thickness	Tab Thickness	Mounting Type	Terminal Style	Stud/Tab Size	Color	Width - Outer Edges	Width - Outer Edges	Termination	Wire Gauge	Insulation	Terminal Type	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Contact Material	Diameter - Ring ID [diameter]	Diameter - Ring ID [diameter]	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Contact Finish	Length - Overall [x]	Length - Overall [x]	Width - Outer Edges [x]	Width - Outer Edges [x]	Diameter - Ring ID	Diameter - Ring ID	Tab Thickness [x]	Tab Thickness [x]	Wire Gauge	Length - Overall	Length - Overall	Diameter - Barrel ID [diameter]
Panduit Corp LCA2-56F-Q	2.54 mm	0.1 in	Free Hanging (In-Line) Right Angle	Single Stud Hole	0.3125 Stud	Brown	16.76 mm	0.66 in	Barrel Crimp	2 AWG	Non-Insulated	Rectangular Tongue
Panduit Corp LCA300-58-X	4.06 mm	0.16 in	Free Hanging (In-Line)	Single Stud Hole	0.625 Stud	White			Barrel Crimp	300 MCM (kcmil)	Non-Insulated	Rectangular Tongue	0.65 in	16.51 mm	Copper	16.76 mm	0.66 in	20.57 mm	0.81 in	Electro-Tin	3.25 in	82.55 mm	30.23 mm	1.19 in
Panduit Corp LCA3/0-12-X			Free Hanging (In-Line)	Single Stud Hole	0.5 Stud		24.38 mm	0.96 in	Barrel Crimp		Non-Insulated	Lug Grounding	0.51 in	12.95 mm	Copper			16.26 mm	0.64 in	Electro-Tin	2.58 in	65.53 mm			13.46 mm	0.53 in	3.3 mm	0.13 in
Panduit Corp LCA10-38-L	1.02 mm	0.04 "	Free Hanging (In-Line)	Single Stud Hole	0.375 Stud		14.22 mm	0.56 in	Barrel Crimp	10 AWG	Non-Insulated	Rectangular Tongue									1.38 in	35.05 mm
Panduit Corp LCA1000-12-3	8.13 mm	0.32 "	Free Hanging (In-Line)	Single Stud Hole	0.5 Stud	White			Barrel Crimp	1000 MCM	Non-Insulated	Rectangular Tongue	1.17 in	29.72 mm	Copper			38.1 mm	1.5 in	Electro-Tin	4.15 "	105.41 mm	55.12 mm	2.17 "	13.46 mm	0.53 in			1000 kcmil
Panduit Corp LCA4/0-12-X	3.56 mm	0.14 in	Free Hanging (In-Line)	Single Stud Hole	0.5 Stud	Purple	26.92 mm		Barrel Crimp	4 aught AWG	Non-Insulated	Lug Grounding												1.06 in						2.67 in	67.82 mm
Panduit Corp LCA8-10F-L	2.03 mm	0.08 "	Free Hanging (In-Line) Right Angle	Single Stud Hole	10 Stud	Red	10.41 mm		Barrel Crimp	8 AWG	Non-Insulated	Rectangular Tongue	0.18 in	4.57 mm	Copper	5.08 mm	0.2 in	6.86 mm	0.27 in	Electro-Tin				0.41 in
Panduit Corp LCA8-10-L	2.03 mm	0.08 "	Free Hanging (In-Line)	Single Stud Hole	10 Stud	Red	10.41 mm		Barrel Crimp	8 AWG	Non-Insulated	Lug Grounding									1.25 "	31.75 mm		0.41 in
Panduit Corp LCA4/0-12F-X	3.56 mm	0.14 in	Free Hanging (In-Line) Right Angle	Single Stud Hole	0.5 Stud	Purple	26.92 mm		Barrel Crimp	4 aught AWG	Non-Insulated	Rectangular Tongue												1.06 in
Panduit Corp LCA750-38-6	6.6 mm	0.26 in	Free Hanging (In-Line)	Single Stud Hole	0.375 Stud	Black			Barrel Crimp	750 MCM	Non-Insulated	Rectangular Tongue		1.03 in	Copper	10.41 mm	0.41 "	33.02 mm	1.3 in	Electro-Tin	3.85 "	97.79 mm	48.01 mm	1.89 in					750 MCM			26.16 mm
