FIG6 Series

Catalog

TERMINALS GROUNDING "FIGURE 6" STYLE CONNECTOR, 25

Part	Termination	Wire Gauge [Min]	Wire Gauge [Max]	Insulation	Color	Terminal Type	Number of Wire Entries	Wire Gauge [Min]	Wire Gauge [Max]	Wire Gauge [Max]	Wire Gauge [Min]
Panduit Corp FIG6-500-2	Crimp	2 AWG 250 MCM (kcmil)	4 AWG 500 MCM (kcmil)	Non-Insulated	Blue	Crimpband Open Band	Varies by Wire Size
Panduit Corp FIG6-500-500	Crimp	250 MCM (kcmil) 350 MCM (kcmil)	500 MCM (kcmil)	Non-Insulated	Blue	Crimpband Open Band	Varies by Wire Size
Panduit Corp FIG6-5/8-26TP	Crimp	2 AWG	6 AWG		Black	Grounding Rod Tap
Panduit Corp FIG6-2-26	Crimp	2 AWG 6 AWG	6 AWG 8 AWG	Non-Insulated	Red	Crimpband Open Band	Varies by Wire Size
Panduit Corp FIG6-500-250	Crimp	250 MCM (kcmil)	500 MCM (kcmil)	Non-Insulated	Blue	Crimpband Open Band	Varies by Wire Size	250 MCM (kcmil)	3/0
Panduit Corp FIG6-500-2/0	Crimp	250 kcmil	500 kcmil	Non-Insulated	Blue	Crimpband Open Band	Varies by Wire Size			1/0	2/0
