842-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 25POS 0.100
| Part | Termination Rows | Material - Insulation | Termination | Contact Material | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Number of Rows | Flange Feature | Pitch | Pitch | Number of Positions/Bay/Row | Mounting Type | Card Type | Gender | Color | Read Out | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Floating Bobbin Flush Mount | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount Side Opening Unthreaded | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount Side Opening Unthreaded | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount Top Opening Unthreaded | 0.1 " | 2.54 mm | 25 | Right Angle Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount Top Opening Unthreaded | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount Top Opening Unthreaded | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Solder | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | 25 | Right Angle Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Wire Wrap | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | 1 | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | 25 | Through Hole | Non Specified - Single Edge | Female | Green | Single | 25 |
