SDEM20161T Series

Catalog

FIXED IND 680NH 2.8A 0.055OHM SM

Part	Current - Saturation (Isat)	Inductance	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	DC Resistance (DCR) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Shielding	Material - Core	Supplier Device Package	Inductance Frequency - Test	DC Resistance (DCR)
Delta Electronics/Cyntec SDEM20161T-R68MS	3.3 A	0.68 µH	20 %	0.039 in	1 mm	55 mOhm	-55 C	125 °C	2.8 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz
Delta Electronics/Cyntec SDEM20161T-6R8MS	1.05 A	6.8 µH	20 %	0.039 in	1 mm	639 mOhm	-55 C	125 °C	0.72 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz
Delta Electronics/Cyntec SDEM20161T-R33MS	4.1 A	330 nH	20 %	0.039 in	1 mm		-55 C	125 °C	3.6 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz	32 mOhm
Delta Electronics/Cyntec SDEM20161T-R47MS	3.9 A	470 nH	20 %	0.039 in	1 mm	41 mOhm	-55 C	125 °C	3 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz
Delta Electronics/Cyntec SDEM20161T-1R0MS	2.7 A	1 µH	20 %	0.039 in	1 mm		-55 C	125 °C	2.4 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz	72 mOhm
Delta Electronics/Cyntec SDEM20161T-1R5MS	2.43 A	1.5 µH	20 %	0.039 in	1 mm	120 mOhm	-55 C	125 °C	2.16 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz
Delta Electronics/Cyntec SDEM20161T-2R2MS	1.7 A	2.2 µH	20 %	0.039 in	1 mm	159 mOhm	-55 C	125 °C	1.6 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz
Delta Electronics/Cyntec SDEM20161T-100MS	720 mA	10 µH	20 %	0.039 in	1 mm	1.01 Ohm	-55 C	125 °C	0.63 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz
Delta Electronics/Cyntec SDEM20161T-R24MS	5.5 A	240 nH	20 %	0.039 in	1 mm		-55 C	125 °C	4.5 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz	24 mOhm
Delta Electronics/Cyntec SDEM20161T-3R3MS	1.35 A	3.3 µH	20 %	0.039 in	1 mm	306 mOhm	-55 C	125 °C	1.08 A	0806 (2016 Metric)	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	Shielded	Metal	2016	1 MHz
