RJMG2 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN JACK 1PORT 1000 BASE-T PCB
| Part | Shield Material | Contact Finish Thickness | Contact Finish Thickness | Housing Material | Termination | Mounting Type | Tab Direction | Features | Contact Material | Shielding | LED Color | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Height Above Board [z] | Height Above Board | Connector Type | Orientation | Number of Ports | Contact Finish | Applications | Number of Cores per Jack | Contact Finish Thickness | Height Above Board [z] | Height Above Board |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Stainless Steel | 30 Áin | 0.76 Ám | Polyester Thermoplastic | Solder | Through Hole | Up | Board Guide | Phosphor Bronze | EMI Finger Shielded | Green - Green | 1 | 70 °C | 0 °C | 0.526 in | 13.36 mm | RJ45 | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 12 | |||
 Amphenol ICC (Commercial Products) | Stainless Steel | Liquid Crystal Polymer (LCP) | Solder | Through Hole | Up | Board Guide | Phosphor Bronze | EMI Finger Shielded | Orange Yellow - Green | 1 | 70 °C | 0 °C | 1.22 in | RJ45 with USB A Dual | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 8 | Flash | 31 mm | ||||
 Amphenol ICC (Commercial Products) | Stainless Steel | 30 Áin | 0.76 Ám | Polyester Thermoplastic | Solder | Board Edge Through Hole | Up | Board Guide | Phosphor Bronze | EMI Finger Shielded | Does Not Contain LED | 1 | 85 °C | -40 C | 11.25 mm | RJ45 | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 12 | 0.443 in | |||
 Amphenol ICC (Commercial Products) | |||||||||||||||||||||||||
 Amphenol ICC (Commercial Products) | Stainless Steel | 50 µin | 1.27 µm | Thermoplastic | Solder | Board Edge Through Hole | Up | Board Guide | Phosphor Bronze | EMI Finger Shielded | Green - Green | 1 | 85 °C | -40 C | 11.3 mm | RJ45 | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 12 | 0.445 in | |||
 Amphenol ICC (Commercial Products) | Stainless Steel | 30 Áin | 0.76 Ám | Polyester Thermoplastic | Solder | Through Hole | Up | Board Guide | Phosphor Bronze | Shielded | Green Yellow - Green | 1 | 70 °C | 0 °C | 11.25 mm | RJ45 | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 8 | 0.443 in | |||
 Amphenol ICC (Commercial Products) | Copper Alloy | 30 Áin | 0.76 Ám | Thermoplastic | Solder | Through Hole | Down | Board Guide | Copper Alloy | EMI Finger Shielded | Green Yellow | 1 | 0.448 in | RJ45 | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 8 | 11.38 mm | |||||
Amphenol ICC (Commercial Products) | Stainless Steel | Glass Filled Thermoplastic | Solder | Through Hole | Phosphor Bronze | EMI Finger Shielded | 1 | 85 °C | -40 C | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 8 | |||||||||||
 Amphenol ICC (Commercial Products) | Stainless Steel | 30 Áin | 0.76 Ám | Glass Filled Thermoplastic | Solder | Through Hole | Up | Board Guide | Phosphor Bronze | EMI Finger Shielded | Orange Yellow - Green | 1 | 85 °C | -40 C | 29.67 mm | RJ45 with USB A Dual | 90 ° | 1 | Gold | 10/100/1000 Base-T AutoMDIX | 8 | 1.168 in |
