TIGK721 Series

Catalog

SWITCH ROCKER DPST 20A 125V

Part	Electrical Life	Mechanical Life	Current Rating (Amps)	Actuator Type	Actuator Marking	Circuit	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Voltage Rating - AC	Approval Agency	Termination Style	Switch Function	Color - Actuator/Cap	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]
Carling Technologies TIGK721-1C-WH-B	50000 Cycles	50000 Cycles	20 A	Concave	No Marking	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	White	Panel Mount Snap-In
Carling Technologies TIGK721-6S-WH-WBL/I-O	50000 Cycles	50000 Cycles	20 A	Concave (Curved)	O I	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	White	Panel Mount Snap-In
Carling Technologies TIGK721-6S-WH-WBL/ON-OFF	50000 Cycles	50000 Cycles	20 A	Concave (Curved)	ON OFF	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	White	Panel Mount Snap-In
Carling Technologies TIGK721-6M-WH-WBL	50000 Cycles	50000 Cycles	20 A	Concave (Curved)	No Marking	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	White	Panel Mount Snap-In	85 °C	-40 C
Carling Technologies TIGK721-6S-WH-NBL	50000 Cycles	50000 Cycles	20 A	Concave (Curved)	No Marking	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	White	Panel Mount Snap-In
Carling Technologies TIGK721-6S-BL-NBL/I-O	50000 Cycles	50000 Cycles	20 A	Concave (Curved)	O I	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	Black	Panel Mount Snap-In
Carling Technologies TIGK721-6S-RD-NBL/I-O	50000 Cycles	50000 Cycles	20 A	Concave (Curved)	O I	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	Red	Panel Mount Snap-In	85 °C	-40 C
Carling Technologies TIGK721-1S-WH-NWH	50000 Cycles	50000 Cycles	20 A	Concave	No Marking	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	White	Panel Mount Snap-In
Carling Technologies TIGK721-1C-WH-NBL	50000 Cycles	50000 Cycles	20 A	Concave	No Marking	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	White	Panel Mount Snap-In
Carling Technologies TIGK721-6S-RD-NBL	50000 Cycles	50000 Cycles	20 A	Concave (Curved)	No Marking	DPST	36.83 mm	21.08 mm	125 V	CSA UL VDE	Quick Connect - 0.250" (6.3mm)	On-Off	Red	Panel Mount Snap-In
