CI0104M1 Series
Manufacturer: Cvilux USA
Beta
⌘K
4 POS 2.00MM(.079) SINGLE ROW SM
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Number of Rows | Contact Type | Termination | Shrouding | Material Flammability Rating | Insulation Color | Contact Material | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Shape | Pitch - Mating | Pitch - Mating | Insulation Height | Insulation Height | Fastening Type | Current Rating (Amps) | Voltage Rating | Contact Length - Mating | Contact Length - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Features | Number of Positions Loaded | Connector Type | Style | Number of Positions | Contact Finish - Post | Mounting Type | Insulation Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | 1 | Male Pin | Solder | Shrouded - 4 Wall | UL94 V-0 | Natural | Brass | 120 µin | 3.05 µm | Square | 0.079 " | 2 mm | 0.263 in | 6.67 mm | Detent Lock | 2 A | 250 VAC | 0.142 in | 3.61 mm | 105 ░C | -25 °C | Pick and Place Solder Retention | All | Header | Board to Cable/Wire | 4 | Tin | Surface Mount | Halogen Free Nylon 6T Polyamide (PA6T) |
