pv1 Series
Manufacturer: E-Switch
Beta
⌘K
SWITCH: VANDAL RESISTANT; POS: 2; PV1; ON PANEL
| Part | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Circuit | Panel Cutout Dimensions [diameter] | Ingress Protection | Voltage Rating - DC | Mounting Type | Type | Actuator Type | Color - Actuator/Cap | Termination Style | Switch Function | Electrical Life | Mechanical Life | Actuator Marking |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 36 VDC | Panel Mount Front | Anti-Vandal | Button Round | Silver | Solder Quick Connect - 0.110" (2.8mm) | Off-Mom | |||
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 48 V | Panel Mount Front | Anti-Vandal | Button Domed Round | Silver | Solder Quick Connect - 0.110" (2.8mm) | Off-Mom | 200000 Cycles | 1000000 Cycles | No Marking |
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 48 V | Panel Mount Front | Anti-Vandal | Button Flush Round | Silver | Screw Terminal | Off-Mom | 200000 Cycles | 1000000 Cycles | No Marking |
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 48 V | Panel Mount Front | Anti-Vandal | Button Flush Round | Silver | Screw Terminal | Off-Mom | 200000 Cycles | 1000000 Cycles | Arrow |
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 48 V | Panel Mount Front | Anti-Vandal | Button Round | Silver | Screw Terminal | Off-Mom | No Marking | ||
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 48 V | Panel Mount Front | Anti-Vandal | Button Round | Silver | Solder Quick Connect - 0.110" (2.8mm) | Off-Mom | 200000 Cycles | 1000000 Cycles | No Marking |
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 48 V | Panel Mount Front | Anti-Vandal | Button Flush Round | Silver | Solder Quick Connect - 0.110" (2.8mm) | Off-Mom | 200000 Cycles | 1000000 Cycles | No Marking |
 E-Switch | 2 A | 55 °C | -20 ░C | SPST-NO | 19 mm | IP65 - Dust Tight Water Resistant | 48 V | Panel Mount Front | Anti-Vandal | Button Flush Round | Black | Screw Terminal | Off-Mom | 200000 Cycles | 1000000 Cycles | No Marking |
