FCRC Series

Catalog

FASTENER, FLAT CABLE CLAMP, NYLON 6.6 (POLYAMIDE 6.6), NATURAL, 2.72 ", 0.625 "

Part	Screw Size	Screw Size	Mounting Type	Opening Size	Opening Size	Length [x]	Length [x]	Height	Height	Width [x]	Width [x]	Color	Panel Hole Size	Panel Hole Size	Material Flammability Rating	Type Attributes	Material	Type	Adhesive	Length	Length	Height [z]	Height [z]
Essentra Components FCRC-19B-6	#12	M5	Fastener	2.31 in	58.67 mm	69.09 mm	2.72 in	20.96 mm	0.825 "	0.625 in	15.88 mm	Natural	5.54 mm	0.218 in	UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat
Essentra Components FCRC-21B-6	#12	M5	Fastener	2.55 in	64.77 mm	75.69 mm	2.98 in	20.96 mm	0.825 "	0.625 in	15.88 mm	Natural	5.54 mm	0.218 in	UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat
Essentra Components FCRC-21B-6A-RT			Adhesive	2.55 in	64.77 mm	75.69 mm	2.98 in	20.96 mm	0.825 "	0.625 in	15.88 mm	Natural			UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat	Acrylic Based (RMS-15)
Essentra Components FCRC-26B-6A-RT			Adhesive	3.24 in	82.3 mm			20.96 mm	0.825 "	0.625 in	15.88 mm	Natural			UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat	Acrylic Based (RMS-15)	92.96 mm	3.66 "
Essentra Components FCRC-26B-6	#12	M5	Fastener	3.24 in	82.3 mm			20.96 mm	0.825 "	0.625 in	15.88 mm	Natural	5.54 mm	0.218 in	UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat		92.96 mm	3.66 "
Essentra Components FCRC-19C			Adhesive Fastener							0.63 in	16 mm	Natural			UL94 V-2	Cover Locking	Polyamide (PA66) Nylon 6/6	Clip Flat		74.17 mm	2.92 in
Essentra Components FCRC-21B-4A-RT			Adhesive	2.55 in	64.77 mm	75.69 mm	2.98 in			0.625 in	15.88 mm	Natural			UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat	Acrylic Based (RMS-15)			0.575 in	14.6 mm
Essentra Components FCRC-19B-4	#12	M5	Fastener	2.31 in	58.67 mm	69.09 mm	2.72 in			0.625 in	15.88 mm	Natural	5.54 mm	0.218 in	UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat				0.575 in	14.6 mm
Essentra Components FCRC-13C			Adhesive Fastener							0.63 in	16 mm	Natural			UL94 V-2	Cover Locking	Polyamide (PA66) Nylon 6/6	Clip Flat
Essentra Components FCRC-26B-4A-RT			Adhesive	3.24 in	82.3 mm					0.625 in	15.88 mm	Natural			UL94 V-2	Base	Polyamide (PA66) Nylon 6/6	Clip Flat	Acrylic Based (RMS-15)	92.96 mm	3.66 "	0.575 in	14.6 mm
