83003 Series

Catalog

HOOK-UP STRND 24AWG BLUE

Part	Qualification	Conductor Material	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Voltage	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Wire Gauge	Length	Length	Ratings	Cable Type	Features	Length [x]	Length [x]
Belden Inc. 83003 0061000	MIL-W-16878/4	Copper Silver Coated	Blue	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG	304.8 m	1000 ft	UL Style 1213	Hook-Up	High Temperature
Belden Inc. 83003 003100	MIL-W-16878/4	Copper Silver Coated	Orange	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG			UL Style 1213	Hook-Up	High Temperature	100 ft	30.5 m
Belden Inc. 83003 0071000	MIL-W-16878/4	Copper Silver Coated	Violet	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG	304.8 m	1000 ft	UL Style 1213	Hook-Up	High Temperature
Belden Inc. 83003 0101000	MIL-W-16878/4	Copper Silver Coated	Black	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG	304.8 m	1000 ft	UL Style 1213	Hook-Up	High Temperature
Belden Inc. 83003 002100	MIL-W-16878/4	Copper Silver Coated	Red	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG			UL Style 1213	Hook-Up	High Temperature	100 ft	30.5 m
Belden Inc. 83003 009500	MIL-W-16878/4	Copper Silver Coated	White	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG	152.4 m	500 ft	UL Style 1213	Hook-Up	High Temperature
Belden Inc. 83003 005100	MIL-W-16878/4	Copper Silver Coated	Green	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG			UL Style 1213	Hook-Up	High Temperature	100 ft	30.5 m
Belden Inc. 83003 0021000	MIL-W-16878/4	Copper Silver Coated	Red	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG	304.8 m	1000 ft	UL Style 1213	Hook-Up	High Temperature
Belden Inc. 83003 0091000	MIL-W-16878/4	Copper Silver Coated	White	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG	304.8 m	1000 ft	UL Style 1213	Hook-Up	High Temperature
Belden Inc. 83003 007100	MIL-W-16878/4	Copper Silver Coated	Violet	0.25 mm	0.01 in	1.12 mm	0.044 in	600 V	Tetrafluoroethylene (TFE)	-70 °C	200 °C	24 AWG			UL Style 1213	Hook-Up	High Temperature	100 ft	30.5 m
