WSE4S Series

Catalog

SENSOR THRU-BEAM 10MM NPN DO/LO

Part	Cable Length	Operating Temperature (Max)	Operating Temperature (Min)	Sensing Distance	Output Configuration	Ingress Protection	Light Source Wavelength (Red)	Light Source	Adjustment Type	Connection Method	Response Time	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Sensing Method
SICK, Inc. 1052880	78.74 in	50 °C	-10 °C	0.394 "	Light-ON NPN - Dark-ON	IP67 IP69K	650 nm	Red	Adjustable Potentiometer	Cable	200 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1052891		70 °C	-30 °C	196.85 "	PNP	IP66 IP67 IP68 IP69K	650 nm	Red		Connector M8	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1061108	5.906 in	70 °C	-30 °C	196.85 "	PNP	IP66 IP67 IP68 IP69K	650 nm	Red		Cable with Connector	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1052872	78.74 in	60 °C	-40 °C	196.85 "	NPN	IP67	650 nm	Red		Cable	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. WSE4S-3P3130V	5.906 in	70 °C	-30 °C	177.165 "	PNP	IP66 IP67 IP68 IP69K	650 nm	Red		Cable with Connector	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1052876		60 °C	-40 °C	196.85 "	NPN	IP67	650 nm	Red		Connector M8	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1067843		60 °C	-40 °C	196.85 "	PNP	IP67	650 nm	Red		Connector M8	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1052888	5.906 in	70 °C	-30 °C	196.85 "	PNP	IP66	650 nm	Red		Cable with Connector	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1054784		70 °C	-30 °C	196.85 "	PNP	IP66 IP67 IP68 IP69K	650 nm	Red		Connector M12	500 µs	10 VDC	30 VDC	Through-Beam
SICK, Inc. 1052890		60 °C	-40 °C	196.85 "	PNP	IP67	650 nm	Red		Connector M8	500 µs	10 VDC	30 VDC	Through-Beam
