HEAVY DUTY POWER CONNECTORS HAN-ECO 16B SMT HSE SNG LVR 2XM40 WO GLN
| Part | Connector Type | Ingress Protection | Features | Lock Location | Style | Operating Temperature [Max] | Operating Temperature [Min] | Housing Color | Housing Material | Size | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size | Thread Size | Size / Dimension [y] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | Base - Box Mount | IP66 - Dust Tight Water Resistant | Feed Through | Locking Clip (1) on Base Bottom | Side Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 16 B | 118 mm | 3.465 " | 4.646 in | 88 mm | 2.559 " | 65 mm | ||||
 HARTING | Hood | IP66 - Dust Tight Water Resistant | Locking Clip (1) on Base Bottom | Side Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 10B | M20 | ||||||||||
 HARTING | Base - Box Mount | IP66 - Dust Tight Water Resistant | Feed Through | Locking Clip (2) on Base Bottom | Side Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 16 B | 118 mm | 3.465 " | 4.646 in | 88 mm | 2.559 " | 65 mm | ||||
 HARTING | Hood | IP66 - Dust Tight Water Resistant | Locking Clip (2) on Base Bottom | Top Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 16 B | |||||||||||
 HARTING | Base - Panel Mount | IP66 - Dust Tight Water Resistant | Locking Clip (2) on Base Bottom | Bottom Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 24 B | 141 mm | 1.421 in | 5.551 " | 2.362 in | 60 mm | 36.1 mm | |||||
 HARTING | Base - Box Mount | IP66 - Dust Tight Water Resistant | Locking Clip (1) on Base Bottom | Side Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 16 B | 118 mm | 3.465 " | 4.646 in | 88 mm | 2.559 " | 65 mm | M25 | ||||
 HARTING | Hood | IP66 - Dust Tight Water Resistant | Locking Clip (1) on Base Bottom | Top Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 10B | M32 | ||||||||||
HARTING | Base - Box Mount | IP66 - Dust Tight Water Resistant | Locking Clip (2) on Base Bottom | Side Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 16 B | 118 mm | 3.465 " | 4.646 in | 88 mm | 2.559 " | 65 mm | |||||
 HARTING | Hood | IP66 - Dust Tight Water Resistant | Locking Clip (2) on Base Bottom | Top Entry | 125 °C | -40 C | Black | Glass Filled Nylon Polyamide (PA) | 10B | M20 |
