846-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 23POS 0.125
| Part | Termination Rows | Material - Insulation | Color | Gender | Contact Material | Read Out | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Pitch | Pitch | Termination | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Number of Positions/Bay/Row | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Solder Eyelet(s) | 1 | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 23 | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Solder | 1 | 0.25 Ám | 10 Áin | 23 | Right Angle Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Solder Eyelet(s) | 1 | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 23 | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Wire Wrap | 1 | 0.25 Ám | 10 Áin | 23 | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Wire Wrap | 1 | 0.25 Ám | 10 Áin | 23 | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | 3.96 mm | 0.156 " | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Wire Wrap | 1 | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | 23 | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | 2.95 mm | 0.116 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Wire Wrap | 1 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 23 | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Solder | 1 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 23 | Right Angle Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | 3.96 mm | 0.156 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Solder | 1 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 23 | Right Angle Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | Female | Copper Alloy | Single | 23 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 3.18 mm | 0.125 in | Solder | 1 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 23 | Right Angle Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Cantilever | 3.96 mm | 0.156 " |
