M467 Series
Manufacturer: Nuvoton Technology Corporation
Beta
⌘K
M4 200MHZ, ETHERNET, CAN FD, USB
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Connectivity | Program Memory Size | Number of I/O | Core Processor | RAM Size | Package / Case | Core Size | Supplier Device Package | Speed | Program Memory Type | Data Converters | Oscillator Type | Peripherals | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nuvoton Technology Corporation | -40 °C | 105 °C | 3.6 V | 1.7 V | CANbus EBI/EMI Ethernet I2C IrDA LINbus QEI QSPI SPI UART/USART USB | 1 MB | 114 | ARM® Cortex®-M4F | 512 K | 144-LQFP | 32-Bit | 144-LQFP (20x20) | 200 MHz | FLASH | A/D 28x12b SAR D/A 2x12b | External Internal | Brown-out Detect/Reset Crypto - AES DMA I2S LCD LVD LVR POR PWM SHA TRNG WDT | Surface Mount |
 Nuvoton Technology Corporation | -40 °C | 105 °C | 3.6 V | 1.7 V | CANbus EBI/EMI Ethernet I2C IrDA LINbus QEI QSPI SPI UART/USART USB | 1 MB | 44 | ARM® Cortex®-M4F | 512 K | 64-LQFP | 32-Bit | 64-LQFP (7x7) | 200 MHz | FLASH | A/D 20x12b SAR D/A 2x12b | External Internal | Brown-out Detect/Reset Crypto - AES DMA I2S LCD LVD LVR POR PWM SHA TRNG WDT | Surface Mount |
 Nuvoton Technology Corporation | -40 °C | 105 °C | 3.6 V | 1.7 V | CANbus EBI/EMI Ethernet I2C IrDA LINbus QEI QSPI SPI UART/USART USB | 1 MB | 146 | ARM® Cortex®-M4F | 512 K | 176-LQFP | 32-Bit | 176-LQFP (24x24) | 200 MHz | FLASH | A/D 28x12b SAR D/A 2x12b | External Internal | Brown-out Detect/Reset Crypto - AES DMA I2S LCD LVD LVR POR PWM SHA TRNG WDT | Surface Mount |
Nuvoton Technology Corporation | -40 ¯C | 85 C | 3.6 V | 1.7 V | CANbus EBI/EMI Ethernet I2C IrDA LINbus QEI QSPI SPI UART/USART USB | 1 MB | 146 | ARM® Cortex®-M4F | 512 K | 176-LQFP | 32-Bit | 176-LQFP (24x24) | 200 MHz | FLASH | A/D 28x12b SAR D/A 2x12b | External Internal | Brown-out Detect/Reset Crypto - AES DMA I2S LCD LVD LVR POR PWM SHA TRNG WDT | Surface Mount |
Nuvoton Technology Corporation | -40 ¯C | 85 C | 3.6 V | 1.7 V | CANbus EBI/EMI Ethernet I2C IrDA LINbus QEI QSPI SPI UART/USART USB | 1 MB | 44 | ARM® Cortex®-M4F | 512 K | 64-LQFP | 32-Bit | 64-LQFP (7x7) | 200 MHz | FLASH | A/D 20x12b SAR D/A 2x12b | External Internal | Brown-out Detect/Reset Crypto - AES DMA I2S LCD LVD LVR POR PWM SHA TRNG WDT | Surface Mount |
Nuvoton Technology Corporation | -40 ¯C | 85 C | 3.6 V | 1.7 V | CANbus EBI/EMI Ethernet I2C IrDA LINbus QEI QSPI SPI UART/USART USB | 1 MB | 114 | ARM® Cortex®-M4F | 512 K | 144-LQFP | 32-Bit | 144-LQFP (20x20) | 200 MHz | FLASH | A/D 28x12b SAR D/A 2x12b | External Internal | Brown-out Detect/Reset Crypto - AES DMA I2S LCD LVD LVR POR PWM SHA TRNG WDT | Surface Mount |
