SIT1602 Series

Manufacturer: SiTime

Catalog

MEMS OSC XO 25.0000MHZ LVCMOS

Part	Current - Supply (Disable) (Max) [Max]	Supplier Device Package [x]	Supplier Device Package	Supplier Device Package [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Base Resonator	Package / Case	Output	Voltage - Supply	Frequency Stability	Frequency	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Height - Seated (Max) [Max]	Height - Seated (Max)	Function	Type	Current - Supply (Max) [Max]	Height - Seated (Max) [Max]	Voltage - Supply [Min]	Voltage - Supply [Max]
SiTime SIT1602AC-11-33E-25.000000	4 mA	2.5	4-PQFN	2	2.5 mm	0.079 in	0.098 in	2 mm	MEMS	4-SMD No Lead	HCMOS LVCMOS	3.3 V	20 ppm	25 MHz	Surface Mount	-20 ░C	70 °C	0.031 in	0.8 mm	Enable/Disable	XO (Standard)	4.5 mA
SiTime SIT1602BI-83-18E-48.000000_6	4.2 mA		4-PQFN (7x5)		7 mm	0.197 "	0.276 "	5 mm	MEMS	4-SMD No Lead	HCMOS LVCMOS	1.8 V	50 ppm	48 MHz	Surface Mount	-40 C	85 °C	0.039 in		Enable/Disable	XO (Standard)	4.5 mA	1 mm
SiTime SIT1602BI-71-YYS-20.000000	4.3 µA		4-PQFN (2x1.6)		2 mm	0.063 "	0.079 in	1.6 mm	MEMS	4-SMD No Lead	HCMOS LVCMOS		20 ppm	20 MHz	Surface Mount	-40 C	85 °C	0.031 in	0.8 mm	Standby (Power Down)	XO (Standard)	4.5 mA		1.62 V	3.63 V
SiTime SIT1602AC-12-33E-33.330000		2.5	4-PQFN	2	2.5 mm	0.079 in	0.098 in	2 mm	MEMS	4-SMD No Lead	LVCMOS	3.3 V	25 ppm	33.33 MHz	Surface Mount	-20 ░C	70 °C	0.031 in	0.8 mm	Enable/Disable	XO (Standard)	4.5 mA
SiTime SIT1602AC-11-33E-33.333330	4 mA	2.5	4-PQFN	2	2.5 mm	0.079 in	0.098 in	2 mm	MEMS	4-SMD No Lead	HCMOS LVCMOS	3.3 V	20 ppm	33.33333 MHz	Surface Mount	-20 ░C	70 °C	0.031 in	0.8 mm	Enable/Disable	XO (Standard)	4.5 mA
SiTime SIT1602BI-72-18E-54.000000_6	4 mA		4-PQFN (2x1.6)		2 mm	0.063 "	0.079 in	1.6 mm	MEMS	4-SMD No Lead	HCMOS LVCMOS	1.8 V	25 ppm	54 MHz	Surface Mount	-40 C	85 °C	0.031 in	0.8 mm	Enable/Disable	XO (Standard)	4.1 mA
SiTime SIT1602AC-12-33S-12.000000		2.5	4-PQFN	2	2.5 mm	0.079 in	0.098 in	2 mm	MEMS	4-SMD No Lead	LVCMOS	3.3 V	25 ppm	12 MHz	Surface Mount	-20 ░C	70 °C	0.031 in	0.8 mm	Standby (Power Down)	XO (Standard)	4.5 mA
SiTime SIT1602AC-12-33E-25.000625		2.5	4-PQFN	2	2.5 mm	0.079 in	0.098 in	2 mm	MEMS	4-SMD No Lead	LVCMOS	3.3 V	25 ppm		Surface Mount	-20 ░C	70 °C	0.031 in	0.8 mm	Enable/Disable	XO (Standard)	4.5 mA
SiTime SIT1602AC-12-33E-3.570000		2.5	4-PQFN	2	2.5 mm	0.079 in	0.098 in	2 mm	MEMS	4-SMD No Lead	LVCMOS	3.3 V	25 ppm	3.57 MHz	Surface Mount	-20 ░C	70 °C	0.031 in	0.8 mm	Enable/Disable	XO (Standard)	4.5 mA
SiTime SIT1602BI-13-25S-25.000000_6	2.5 µA	2.5	4-PQFN	2	2.5 mm	0.079 in	0.098 in	2 mm	MEMS	4-SMD No Lead	HCMOS LVCMOS	2.5 V	50 ppm	25 MHz	Surface Mount	-40 C	85 °C	0.031 in	0.8 mm	Standby (Power Down)	XO (Standard)	4.2 mA
