628 (Metal) Series

Manufacturer: EDAC Inc.

Catalog

D-SUB STANDARD CONNECTORS VERTICAL METAL BODY D-SUB CONNECTOR

Part	Connector Style	Connector Type	Number of Positions	Number of Rows [custom]	Current Rating (Amps)	Mounting Type	Features	Shell Size, Connector Layout	Contact Type	Contact Finish Thickness	Contact Finish Thickness	Material Flammability Rating	Flange Feature	Contact Finish	Termination	Shell Size, Connector Layout	Contact Finish Thickness	Shell Material, Finish	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [x]	Dielectric Material	Contact Material	Color	Operating Temperature [Min]	Operating Temperature [Max]
EDAC Inc. 628-015-381-257	D-Sub	Receptacle Female Sockets	15	2	3 A	Through Hole	Board Lock Shielded	2	Signal	0.38 µm	15 µin	UL94 V-0	Board Side (4-40)	Gold	Solder
EDAC Inc. 628-037-241-256	D-Sub	Receptacle Female Sockets	37	2	3 A	Through Hole	Board Lock Shielded	4	Signal and Power			UL94 V-0	Board Side (4-40)	Gold	Solder	DC C	Flash
EDAC Inc. 628-050-320-067	D-Sub	Receptacle Female Sockets	50	3	3 A	Through Hole	Board Lock Shielded		Signal and Power	0.38 µm	15 µin	UL94 V-0	Board Side (4-40)	Gold	Solder			Nickel Plated Steel	5	D DD
EDAC Inc. 628-015-322-069	D-Sub	Receptacle Female Sockets	15	2	3 A	Free Hanging (In-Line)	Shielded	2	Signal	0.38 µm	15 µin	UL94 V-0	Board Side (4-40)	Gold				Nickel Plated Steel
EDAC Inc. 628-037-220-061	D-Sub	Receptacle Female Sockets	37	2	3 A	Through Hole	Shielded	4	Signal			UL94 V-0	Board Side (4-40)	Gold	Solder	DC C	Flash	Nickel Plated Steel
EDAC Inc. 628-009-322-261	D-Sub	Receptacle Female Sockets	9	2	3 A	Free Hanging (In-Line)	Shielded		Signal and Power	0.38 µm	15 µin	UL94 V-0	Board Side (4-40)	Gold					1	DE E
EDAC Inc. 628-015-221-073	D-Sub	Receptacle Female Sockets	15	2	3 A	Through Hole	Shielded	2	Signal and Power			UL94 V-0	Board Side (4-40)	Gold	Solder		Flash	Nickel Plated Steel
EDAC Inc. 628-025-641-076	D-Sub	Receptacle Female Sockets	25	2	3 A	Through Hole	Board Lock Shielded		Signal	0.76 Ám	30 Áin	UL94 V-0	Board Side (4-40)	Gold	Solder	B DB		Nickel Plated Steel			3
EDAC Inc. 628-037-361-276	D-Sub	Receptacle Female Sockets	37	2	3 A	Through Hole	Board Lock Shielded	4	Signal and Power	0.38 µm	15 µin	UL94 V-0	Board Side (4-40)	Gold	Solder	DC C
EDAC Inc. 628-050-622-063	D-Sub	Receptacle Female Sockets	50	3	5 A	Free Hanging (In-Line)	Shielded		Signal and Power	0.76 Ám	30 Áin	UL94 V-0	Board Side (4-40)	Gold				Nickel Plated Steel	5	D DD		Polyester Thermoplastic	Brass	Black	-55 C	85 °C
