RS612 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CMC 3UH 4A 2LN TH

Part	Package / Case	Height (Max) [Max] [z]	Height (Max)	DC Resistance (DCR) (Max)	Approval Agency	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Max)	Voltage Rating - AC	Number of Lines	Filter Type	Inductance @ Frequency	Current	Voltage - Rated AC	Inductance	Applications	Configuration	Frequency - Operating	DC Resistance (DCR) (Max) [Max]
TE Connectivity AMP Connectors RS612-4-02	Vertical 4 PC Pin	0.787 in	20 mm	10 mOhm	UR VDE	Through Hole	12.5 mm	18 mm	0.709 in	0.492 "	125 °C	-40 C	4 A	250 V	2	Signal Line	1 kHz 3 µH
TE Connectivity AMP Connectors RS612-2-02						Through Hole					125 °C	-40 C				Single Phase		2 A	250 V	56 µH	General Purpose	Single Stage	DC ~ 400Hz
TE Connectivity AMP Connectors RS612-2-02						Through Hole					125 °C	-40 C				Single Phase		2 A	250 V	56 µH	General Purpose	Single Stage	DC ~ 400Hz
TE Connectivity AMP Connectors RS612-0.5-02	Vertical 4 PC Pin	0.787 in	20 mm	650 mOhm	UR VDE	Through Hole	12.5 mm	18 mm	0.709 in	0.492 "	125 °C	-40 C	500 mA	250 V	2	Signal Line	200 µH
TE Connectivity AMP Connectors RS612-1-02	Vertical 4 PC Pin	0.787 in	20 mm		UR VDE	Through Hole	12.5 mm	18 mm	0.709 in	0.492 "	125 °C	-40 C	1 A	250 V	2	Signal Line	1 kHz 55 µH							130 mOhm
TE Connectivity AMP Connectors RS612-1-02	Vertical 4 PC Pin	0.787 in	20 mm		UR VDE	Through Hole	12.5 mm	18 mm	0.709 in	0.492 "	125 °C	-40 C	1 A	250 V	2	Signal Line	1 kHz 55 µH							130 mOhm
TE Connectivity AMP Connectors RS612-0.5-02	Vertical 4 PC Pin	0.787 in	20 mm	650 mOhm	UR VDE	Through Hole	12.5 mm	18 mm	0.709 in	0.492 "	125 °C	-40 C	500 mA	250 V	2	Signal Line	200 µH
TE Connectivity AMP Connectors RS612-4-02	Vertical 4 PC Pin	0.787 in	20 mm	10 mOhm	UR VDE	Through Hole	12.5 mm	18 mm	0.709 in	0.492 "	125 °C	-40 C	4 A	250 V	2	Signal Line	1 kHz 3 µH
