8060 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN TRANSIST TO-5 4POS GOLD
| Part | Number of Positions or Pins (Grid) | Contact Finish - Post | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Type | Contact Finish - Mating | Housing Material | Contact Material - Post | Features | Termination | Contact Material - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 4 | Gold | -55 C | 125 °C | Through Hole | Transistor TO-5 | Gold | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Closed Frame | Solder | Beryllium Copper |
 TE Connectivity AMP Connectors | 3 | Gold | -55 C | 125 °C | Panel Mount | Transistor TO-5 | Gold | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Closed Frame | Solder | Beryllium Copper |
 TE Connectivity AMP Connectors | 3 | Gold | -55 C | 125 °C | Through Hole | Transistor TO-5 | Gold | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Closed Frame | Solder | Beryllium Copper |
 TE Connectivity AMP Connectors | 3 | Gold | -55 C | 125 °C | Through Hole | Transistor TO-5 | Gold | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Closed Frame | Solder | Beryllium Copper |
TE Connectivity AMP Connectors | 3 | Gold | -55 C | 125 °C | Through Hole | Transistor TO-5 | Gold | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Closed Frame | Solder | Beryllium Copper |
TE Connectivity AMP Connectors | 3 | Transistor TO-5 | Gold | Solder | ||||||||
 TE Connectivity AMP Connectors | 3 | Gold | -55 C | 125 °C | Through Hole | Transistor TO-5 | Gold | Polytetrafluoroethylene (PTFE) | Beryllium Copper | Closed Frame | Solder | Beryllium Copper |
