837-033 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 33POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions [custom] | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Positions/Bay/Row | Flange Feature | Termination | Number of Rows | Contact Material | Gender | Mounting Type | Color | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Card Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | 4-40 Flush Mount Threaded Insert Top Opening | Solder | 1 | Copper Alloy | Female | Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | Solder | 1 | Copper Alloy | Female | Right Angle Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | M3 Threaded Insert Top Mount Opening | Wire Wrap | 1 | Copper Alloy | Female | Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | Flush Mount Side Opening Unthreaded | Solder | 1 | Copper Alloy | Female | Right Angle Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | Solder | 1 | Copper Alloy | Female | Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | Floating Bobbin Top Mount Opening | Solder Eyelet(s) | 1 | Copper Alloy | Female | Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | Floating Bobbin Top Mount Opening | Wire Wrap | 1 | Copper Alloy | Female | Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | M3 Threaded Insert Top Mount Opening | Wire Wrap | 1 | Copper Alloy | Female | Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | Flush Mount Top Opening Unthreaded | Solder | 1 | Copper Alloy | Female | Right Angle Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 33 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 33 | Solder | 1 | Copper Alloy | Female | Through Hole | Green | Single | 125 °C | -40 C | Cantilever | Non Specified - Single Edge |
