D09P33 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
D09P33E4GL00 DSUB R/A STB 9 PIN
| Part | Mounting Type | Dielectric Material | Connector Type | Contact Material | Termination | Connector Style | Number of Positions | Number of Rows | Backset Spacing | Backset Spacing | Contact Type | Voltage Rating | Features | Flange Feature | Current Rating (Amps) | Material Flammability Rating | Contact Finish | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish Thickness | Shell Material, Finish | Primary Material | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | Through Hole Right Angle | Thermoplastic | Male Pins Plug | Brass | Solder | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Board Lock Grounding Indents Mounting Brackets | Housing/Shell (M3) | 5 A | UL94 V-0 | Gold | DE E | 1 | Black | -55 °C | 125 °C | Flash | |||||
 Amphenol ICC (FCI) | Through Hole Right Angle | Polybutylene Terephthalate (PBT) | Male Pins Plug | Brass | Solder | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Board Lock Grounding Indents Mounting Brackets | Housing/Shell (4-40) | 5 A | UL94 V-0 | Gold or Gold GXT™ | DE E | 1 | Black | -55 °C | 125 °C | 0.76 Ám | 30 Áin | Steel Tin-Nickel Plated | |||
Amphenol ICC (FCI) | Through Hole Right Angle | Thermoplastic | Male Pins Plug | Copper Alloy | Solder | D-Sub | 9 | 2 | 10.4 mm | 0.409 in | Signal | Grounding Indents | Housing/Shell (M3) | 5 A | UL94 V-0 | Gold | DE E | 1 | Black | -55 °C | 125 °C | Flash | Metal | |||||
Amphenol ICC (FCI) | Through Hole Right Angle | Polybutylene Terephthalate (PBT) | Male Pins Plug | Brass | Solder | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Board Lock Grounding Indents Mounting Brackets | Female Screwlock (4-40) Mating Side | 5 A | UL94 V-0 | Gold or Gold GXT™ | DE E | 1 | Black | -55 °C | 125 °C | 0.76 Ám | 30 Áin | ||||
Amphenol ICC (FCI) | Through Hole Right Angle | Male Pins Plug | Phosphor Bronze | Solder | D-Sub | 9 | 2 | Signal | 300 VDC | Grounding Indents | Female Screwlock (M3) Mating Side | 5 A | UL94 V-0 | Gold | DE E | 1 | -55 °C | 125 °C | Steel Tin-Nickel Plated | |||||||||
 Amphenol ICC (FCI) | Through Hole Right Angle | Glass Filled Nylon Polyamide (PA) | Male Pins Plug | Brass | Solder Paste | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Board Guide Grounding Indents Mounting Brackets | Female Screwlock (4-40) Mating Side | 5 A | UL94 V-0 | Gold or Gold GXT™ | DE E | 1 | Black | 0.76 Ám | 30 Áin | Nickel Plated Steel | -55 °C | ||||
Amphenol ICC (FCI) | Through Hole Right Angle | Thermoplastic | Male Pins Plug | Brass | Solder | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Board Lock Grounding Indents Mounting Brackets | Housing/Shell (M3) | 5 A | UL94 V-0 | Gold or Gold GXT™ | DE E | 1 | Black | -55 °C | 125 °C | 0.76 Ám | 30 Áin | ||||
 Amphenol ICC (FCI) | Through Hole Right Angle | Polybutylene Terephthalate (PBT) | Male Pins Plug | Brass | Solder | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Board Lock Grounding Indents Mounting Brackets | Female Screwlock (4-40) Mating Side | 5 A | UL94 V-0 | Gold | DE E | 1 | Black | -55 °C | 125 °C | Flash | Steel Tin-Nickel Plated | ||||
Amphenol ICC (FCI) | Through Hole Right Angle | Glass Filled Nylon Polyamide (PA) | Male Pins Plug | Brass | Solder Paste | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Board Guide Grounding Indents Mounting Brackets | Female Screwlock (4-40) Mating Side | 5 A | UL94 V-0 | Gold or Gold GXT™ | DE E | 1 | Black | 0.76 Ám | 30 Áin | Nickel Plated Steel | -55 °C | ||||
Amphenol ICC (FCI) | Through Hole Right Angle | Polyester | Male Pins Plug | Brass | Solder | D-Sub | 9 | 2 | 8.08 mm | 0.318 " | Signal | 300 VDC | Grounding Indents Mounting Brackets | Female Screwlock (4-40) Mating Side | 5 A | UL94 V-0 | Gold | DE E | 1 | Black | -55 °C | 125 °C | 0.76 Ám | 30 Áin |
