PX0580 Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
CONN IEC 60320 C14 INLET M 3 POS SOLDER ST THRU-HOLE 3 TERMINAL 1 PORT BULK
| Part | Voltage Rating - Appliance Inlet | Current Rating - Appliance Inlet | Filter Type | Connector Type | Accomodates a Fuse | Panel Thickness | Panel Thickness | Material Flammability Rating | Termination | Features | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Connector Style | Mounting Type | Approval Agency | Panel Cutout Dimensions | Termination | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | 250 VAC | 10 A | Unfiltered - Commercial | Receptacle Male Blades | 0.126 in | 3.2 mm | UL94 V-0 | Solder | Terminating Cover | 22.48 mm | 30.25 mm | IEC 320-C14 | Panel Mount Flange Through Hole Right Angle | CSA ENEC UL VDE | ||||
 BULGIN LIMITED | 250 VAC | 10 A | Unfiltered - Commercial | Receptacle Male Blades | UL94 V-0 | Screw | Front or Rear Side Mount | IEC 320-C14 | Flange Panel Mount | CSA ENEC UL VDE | Variable Size | |||||||
 BULGIN LIMITED | 250 VAC | 10 A | Unfiltered - Commercial | Receptacle Male Blades | UL94 V-0 | Quick Connect | Front or Rear Side Mount | IEC 320-C14 | Flange Panel Mount | CSA ENEC UL VDE | Variable Size | 0.189 " | 4.8 mm | |||||
 BULGIN LIMITED | 250 VAC | 10 A | Unfiltered - Commercial | Receptacle Male Blades | UL94 V-0 | Quick Connect | Front or Rear Side Mount | IEC 320-C14 | Flange Panel Mount | CSA ENEC UL VDE | Variable Size | 0.25 " | 6.3 mm | |||||
 BULGIN LIMITED | 250 VAC | 10 A | Unfiltered - Commercial | Receptacle Male Blades | 0.126 in | 3.2 mm | UL94 V-0 | Solder | 22.48 mm | 30.25 mm | IEC 320-C14 | Panel Mount Flange Through Hole Right Angle | CSA ENEC UL VDE |
