424-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE METAL TO METAL 2 PIECE CONNECTORS ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Contact Material | Color | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness | Card Thickness | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Rows [custom] | Termination | Number of Positions | Mounting Type | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1.57 mm | 0.062 in | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1.57 mm | 0.062 in | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Wire Wrap | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Wire Wrap | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder Eyelet(s) | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1.57 mm | 0.062 in | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Green | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2.36 mm | 0.093 " | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | Solder | 29 | Panel Mount Through Hole | Female | -65 ░C | 125 °C | 5.08 mm | 0.2 in |
