940-44 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN SKT PLCC
| Part | Material Flammability Rating | Termination | Type | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Pitch - Post | Pitch - Post | Mounting Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Features | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) | Current Rating (Amps) | Contact Resistance | Termination Post Length | Termination Post Length | Housing Material | Contact Material - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material - Post | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [y] | Number of Positions or Pins (Grid) [x] | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 1.27 mm | 0.05 in | 0.05 in | 1.27 mm | Surface Mount | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 4 x 13 | 52 | ||||||||||||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 2.54 mm | 0.1 " | 0.1 in | 2.54 mm | Through Hole | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 1 A | 30 mOhm | 3.3 mm | 0.13 in | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | -55 C | 125 °C | Brass Alloy | |||||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 2.54 mm | 0.1 " | 0.1 in | 2.54 mm | Through Hole | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 20 | 1 A | 30 mOhm | 3.3 mm | 0.13 in | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | -55 C | 125 °C | Brass Alloy | 5 | 4 | ||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 1.27 mm | 0.05 in | 0.05 in | 1.27 mm | Surface Mount | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 28 | 1 A | 30 mOhm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | -55 C | 125 °C | Brass Alloy | ||||||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 1.27 mm | 0.05 in | 0.05 in | 1.27 mm | Surface Mount | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 44 | 11 | 4 | |||||||||||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 1.27 mm | 0.05 in | 0.05 in | 1.27 mm | Surface Mount | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 1 A | 30 mOhm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | -55 C | 125 °C | Brass Alloy | 4 | 17 | 68 | ||||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 1.27 mm | 0.05 in | 0.05 in | 1.27 mm | Surface Mount | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 1 A | 30 mOhm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | -55 C | 125 °C | Brass Alloy | 4 | 17 | 68 | ||||||||
Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 1.27 mm | 0.05 in | 0.05 in | 1.27 mm | Surface Mount | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 32 | 7 9 | 2 | |||||||||||||||
 Mill-Max Manufacturing Corp. | UL94 V-0 | Solder | PLCC | Tin | 1.27 mm | 0.05 in | 0.05 in | 1.27 mm | Surface Mount | 150 Áin | 3.81 Ám | 200 µin | 5.08 µm | Closed Frame | 20 | 1 A | 30 mOhm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | -55 C | 125 °C | Brass Alloy | 5 | 4 |
