EKY-100E Series

Manufacturer: Chemi-Con

Catalog

CAP ALUM 680UF 20% 10V RADIAL

Part	Polarization	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Ripple Current @ Low Frequency	Lifetime @ Temp.	Impedance	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Lead Spacing	Lead Spacing	Ripple Current @ High Frequency	Capacitance	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Tolerance	Applications	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max)
Chemi-Con EKY-100ELL681MH15D	Polar	0.65 in	16.5 mm	504 mA	6000 Hrs	87 mOhms	10 V	0.315 in	8 mm	Through Hole	0.138 in	3.5 mm	840 mA	680 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose
Chemi-Con EKY-100ELL562ML25S	Polar	1.043 in	26.5 mm	2.4905 A	8000 Hrs	21 mOhms	10 V	0.63 in	16 mm	Through Hole	0.295 in	7.5 mm	2.93 A	5.6 mF	Can Radial	-40 C	105 ░C	20 %	General Purpose
Chemi-Con EKY-100ELL681MJC5S	Polar			519 mA	6000 Hrs	80 mOhms	10 V	0.394 in	10 mm	Through Hole	0.197 "	5 mm	865 mA	680 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose	14 mm	0.551 in
Chemi-Con EKY-100ELL102MJ16S	Polar		0.689 in	726 mA	6000 Hrs	60 mOhms	10 V	0.394 in	10 mm	Through Hole	0.197 "	5 mm	1.21 A	1000 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose			17.5 mm
Chemi-Con EKY-100ELL102MH20D	Polar			630 mA	6000 Hrs	69 mOhms	10 V	0.315 in	8 mm	Through Hole	0.138 in	3.5 mm	1.05 A	1000 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose	21.5 mm	0.846 "
Chemi-Con EKY-100ETD102MH20D	Polar			630 mA	6000 Hrs	69 mOhms	10 V	0.315 in	8 mm	Through Hole	0.138 in	3.5 mm	1.05 A	1000 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose	21.5 mm	0.846 "
Chemi-Con EKY-100ETD222MK20S	Polar			1.425 A	8000 Hrs	35 mOhms	10 V	0.492 in	12.5 mm	Through Hole	0.197 "	5 mm		2200 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose	21.5 mm	0.846 "
Chemi-Con EKY-100ELL101ME11D	Polar			84 mA	4000 Hrs	580 mOhms	10 V	0.197 in	5 mm	Through Hole	0.079 in	2 mm	210 mA	100 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose	0.492 in			12.5 mm
Chemi-Con EKY-100ELL472MK35S	Polar	1.437 "	36.5 mm	2.448 A	8000 Hrs	20 mOhms	10 V	0.492 in	12.5 mm	Through Hole	0.197 "	5 mm	2.88 A	4700 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose
Chemi-Con EKY-100ELL103MMP1S	Polar	1.457 in		3.587 A	8000 Hrs	14 mOhms	10 V	0.709 in	18 mm	Through Hole	0.295 in	7.5 mm	4.22 A	10000 µF	Can Radial	-40 C	105 ░C	20 %	General Purpose					37 mm
