892-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 9POS 0.100
| Part | Termination Rows | Material - Insulation | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Read Out | Card Type | Gender | Color | Termination | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Number of Positions/Bay/Row | Number of Positions | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Wire Wrap | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Solder | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Wire Wrap | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Wire Wrap | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Solder | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Solder | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Wire Wrap | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Solder | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Wire Wrap | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | 0.1 " | 2.54 mm | Single | Non Specified - Single Edge | Female | Black | Solder | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 9 | 9 | Gold |
