306-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 21 CONTACTS, PANEL MOUNT, STRAIGHT
| Part | Termination Rows | Material - Insulation | Card Type | Flange Feature | Pitch | Pitch | Number of Rows [custom] | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Termination | Contact Material | Contact Finish | Number of Positions/Bay/Row [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Color | Read Out | Contact Finish Thickness | Contact Finish Thickness | Features | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Solder Eyelet(s) | Copper Alloy | Gold | 21 | -40 C | 105 ░C | Female | Green | Dual | 0.25 Ám | 10 Áin | Card Guides | Cantilever | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Copper Alloy | Gold | 21 | -40 C | 105 ░C | Female | Green | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | Floating Bobbin Flush Mount | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Solder Eyelet(s) | Copper Alloy | Gold | 21 | -40 C | 105 ░C | Female | Green | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.116 " | 2.95 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Solder Eyelet(s) | Copper Alloy | Gold | 21 | -40 C | 105 ░C | Female | Green | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Solder Eyelet(s) | Copper Alloy | Tin | 21 | -40 C | 105 ░C | Female | Green | Dual | Cantilever | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Copper Alloy | Gold | 21 | -40 C | 105 ░C | Female | Green | Dual | 0.25 Ám | 10 Áin | Card Guides | Cantilever | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Copper Alloy | Gold | 21 | -40 C | 105 ░C | Female | Green | Dual | 0.25 Ám | 10 Áin | Cantilever | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Copper Alloy | Tin | 21 | -40 C | 105 ░C | Female | Green | Dual | Cantilever | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Solder Eyelet(s) | Copper Alloy | Tin | 21 | -40 C | 105 ░C | Female | Green | Dual | Cantilever | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 2 | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Copper Alloy | Gold | 21 | -40 C | 105 ░C | Female | Green | Dual | 0.25 Ám | 10 Áin | Card Guides | Cantilever |
