EB21A Series
Manufacturer: Adam Tech
Beta
⌘K
EURO BLOCK 2P
| Part | Screw Thread | Clamp Material - Plating | Contact Material - Plating | Torque - Screw | Torque - Screw | Operating Temperature [Min] | Operating Temperature [Max] | Screw Material - Plating | Number of Levels | Wire Termination | Pitch | Pitch | Current | Wire Gauge [Max] | Wire Gauge [Min] | Features | Voltage | Mating Orientation | Color | Mounting Type | Positions Per Level |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | M2.5 | Brass - Nickel Plated | Brass - Tin Plated | 3.5 Lb-In | 0.4 Nm | -40 C | 105 ░C | Steel - Zinc Plated | 1 | Screw - Rising Cage Clamp | 0.197 in | 5 mm | 8 A | 26 AWG | 16 AWG | Interlocking (Side) | 300 VDC | Horizontal with Board | Green | Through Hole | 2 |
 Adam Tech | M2.5 | Brass - Nickel Plated | Brass - Tin Plated | 3.5 Lb-In | 0.4 Nm | -40 C | 105 ░C | Steel - Zinc Plated | 1 | Screw - Rising Cage Clamp | 0.197 in | 5 mm | 8 A | 26 AWG | 16 AWG | Interlocking (Side) | 300 VDC | Horizontal with Board | Green | Through Hole | 4 |
 Adam Tech | M2.5 | Brass - Nickel Plated | Brass - Tin Plated | 3.5 Lb-In | 0.4 Nm | -40 C | 105 ░C | Steel - Zinc Plated | 1 | Screw - Rising Cage Clamp | 0.197 in | 5 mm | 8 A | 26 AWG | 16 AWG | Interlocking (Side) | 300 VDC | Horizontal with Board | Green | Through Hole | 6 |
 Adam Tech | M2.5 | Brass - Nickel Plated | Brass - Tin Plated | 3.5 Lb-In | 0.4 Nm | -40 C | 105 ░C | Steel - Zinc Plated | 1 | Screw - Rising Cage Clamp | 0.197 in | 5 mm | 8 A | 26 AWG | 16 AWG | Interlocking (Side) | 300 VDC | Horizontal with Board | Green | Through Hole | 3 |
Adam Tech | M2.5 | Brass - Nickel Plated | Brass - Tin Plated | 3.5 Lb-In | 0.4 Nm | -40 C | 105 ░C | Steel - Zinc Plated | 1 | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 8 A | 26 AWG | 16 AWG | Interlocking (Side) | 300 VDC | Horizontal with Board | Green | Through Hole | 6 |
 Adam Tech | M2.5 | Brass - Nickel Plated | Brass - Tin Plated | 3.5 Lb-In | 0.4 Nm | -40 C | 105 ░C | Steel - Zinc Plated | 1 | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 8 A | 26 AWG | 16 AWG | Interlocking (Side) | 300 VDC | Horizontal with Board | Green | Through Hole | 5 |
 Adam Tech | M2.5 | Brass - Nickel Plated | Brass - Tin Plated | 3.5 Lb-In | 0.4 Nm | -40 C | 105 ░C | Steel - Zinc Plated | 1 | Screw - Rising Cage Clamp | 0.2 in | 5.08 mm | 8 A | 26 AWG | 16 AWG | Interlocking (Side) | 300 VDC | Horizontal with Board | Green | Through Hole | 2 |
