837-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 28POS 0.156
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Color | Contact Type | Mounting Type | Termination | Read Out | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Gender | Card Type | Number of Positions | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 28 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Through Hole | Wire Wrap | Single | 1 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Female | Non Specified - Single Edge | 28 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 28 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Right Angle Through Hole | Solder | Single | 1 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold | Female | Non Specified - Single Edge | 28 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Through Hole | Solder | Dual | 4-40 Threaded Insert Top Mount Opening | Gold | Female | Non Specified - Dual Edge | 28 | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Through Hole | Solder | Dual | M3 Threaded Insert Top Mount Opening | Gold | Female | Non Specified - Dual Edge | 28 | 2 | 2 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 28 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Through Hole | Solder Eyelet(s) | Single | 1 | Flush Mount M3 Threaded Insert Top Opening | Gold | Female | Non Specified - Single Edge | 28 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 28 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Right Angle Through Hole | Solder | Single | 1 | Gold | Female | Non Specified - Single Edge | 28 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Through Hole | Solder | Dual | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Female | Non Specified - Dual Edge | 28 | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Board Edge Straddle Mount | Solder | Dual | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Gold | Female | Non Specified - Dual Edge | 28 | 2 | 2 | Card Extender | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 28 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Through Hole | Wire Wrap | Single | 1 | 4-40 Threaded Insert Top Mount Opening | Gold | Female | Non Specified - Single Edge | 28 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 14 | 0.25 Ám | 10 Áin | Copper Alloy | Green | Cantilever | Right Angle Through Hole | Solder | Dual | M3 Threaded Insert Top Mount Opening | Gold | Female | Non Specified - Dual Edge | 28 | 2 | 2 |
