1734577 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RJ45 8P8C SHD W/O LED 50U" AU HDT
| Part | Housing Material | Shielding | Number of Ports | Number of Positions/Contacts | Mounting Type | Tab Direction | Connector Type | Orientation | Contact Finish | Contact Material | Features | Termination | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | LED Color | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Board Lock | Solder | 1 | ||||
 TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Board Lock | Solder | 1 | 50 µin | 1.27 µm | Does Not Contain LED | Cat3 |
 TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Solder | 1 | 50 µin | 1.27 µm | Green - Yellow | Cat3 | |
 TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Board Lock | Solder | 1 | 6 Áin | 0.152 Ám | Green - Yellow | Cat3 |
 TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Board Lock | Solder | 1 | 50 µin | 1.27 µm | Green - Green | Cat3 |
 TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Board Lock | Solder | 1 | 50 µin | 1.27 µm | Green - Yellow | Cat3 |
TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Board Lock | Solder | 1 | 30 Áin | 0.76 Ám | Green Orange Yellow | |
 TE Connectivity AMP Connectors | Polyamide (PA46) Nylon 4/6 Glass Filled | Shielded | 1 | 8p8c (RJ45 Ethernet) | Through Hole | User Selectable | Jack | Vertical | Gold | Phosphor Bronze | Board Lock | Solder | 1 | 15 µin | 0.38 µm | Green - Yellow | Cat3 |
