853-47 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RCPT 58P 0.05 GOLD PCB R/A

Part	Insulation Material	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Shape	Material Flammability Rating	Number of Positions Loaded	Insulation Color	Current Rating (Amps)	Number of Rows [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Insulation Height	Insulation Height	Contact Finish - Mating	Contact Length - Post [custom]	Contact Length - Post [custom]	Row Spacing - Mating	Row Spacing - Mating	Mounting Type	Number of Positions	Contact Type	Termination	Connector Type	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Mating	Contact Finish - Post	Contact Length - Post	Contact Length - Post	Number of Positions [custom]
Mill-Max Manufacturing Corp. 853-47-058-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	3.05 mm	0.12 in	Gold	0.135 in	3.43 mm	0.05 in	1.27 mm	Right Angle Through Hole	58	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin
Mill-Max Manufacturing Corp. 853-47-070-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	3.05 mm	0.12 in	Gold	0.135 in	3.43 mm	0.05 in	1.27 mm	Right Angle Through Hole	70	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin
Mill-Max Manufacturing Corp. 853-47-012-10-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	4.01 mm	0.158 in	Gold			0.05 in	1.27 mm	Through Hole	12	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin	2.6 mm	0.102 in
Mill-Max Manufacturing Corp. 853-47-022-10-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	4.01 mm	0.158 in	Gold			0.05 in	1.27 mm	Through Hole	22	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin	2.6 mm	0.102 in
Mill-Max Manufacturing Corp. 853-47-076-10-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	4.01 mm	0.158 in	Gold			0.05 in	1.27 mm	Through Hole	76	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin	2.6 mm	0.102 in
Mill-Max Manufacturing Corp. 853-47-048-10-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	4.01 mm	0.158 in	Gold			0.05 in	1.27 mm	Through Hole	48	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin	2.6 mm	0.102 in
Mill-Max Manufacturing Corp. 853-47-012-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	3.05 mm	0.12 in	Gold	0.135 in	3.43 mm	0.05 in	1.27 mm	Right Angle Through Hole	12	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin
Mill-Max Manufacturing Corp. 853-47-068-20-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	3.05 mm	0.12 in	Gold	0.135 in	3.43 mm	0.05 in	1.27 mm	Right Angle Through Hole	68 positions	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin
Mill-Max Manufacturing Corp. 853-47-054-10-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	4.01 mm	0.158 in	Gold			0.05 in	1.27 mm	Through Hole	54	Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin	2.6 mm	0.102 in
Mill-Max Manufacturing Corp. 853-47-084-10-001000	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Beryllium Copper	200 µin	5.08 µm	Circular	UL94 V-0	All	Black	3 A	2	-55 C	125 °C	Push-Pull	4.01 mm	0.158 in	Gold			0.05 in	1.27 mm	Through Hole		Female Socket	Solder	Receptacle	1.27 mm	0.05 in	Flash	Tin	2.6 mm	0.102 in	84
