FX8RP7 Series

Catalog

FIBER OPTIC CABLE ASSEMBLIES OM3 8 FIBER ROUND HARNESS PLENUM PANMPO

Part	Color - Connectors	Bend Radius [radius]	Operating Temperature [Min]	Operating Temperature [Max]	Return Loss	Insertion Loss	Fiber Type	Type	Cable Diameter [diameter]	Cable Diameter [diameter]	2nd Connector	Length - Overall [x]	Length - Overall [x]	1st Connector	Length - Overall	Length - Overall
Panduit Corp FX8RP7NUSQNF025	Black	30 mm	0 °C	60 °C	26 dB	0.75 dB	50/125	Multimode OM3	3 mm	0.12 in	LC	7.6 m	25 ft	MPO
Panduit Corp FX8RP7NQSVNF015
Panduit Corp FX8RP7NQSVNF024
Panduit Corp FX8RP7NUSQNF070	Black	30 mm	0 °C	60 °C	26 dB	0.75 dB	50/125	Multimode OM3	3 mm	0.12 in	LC	21.3 m	70 ft	MPO
Panduit Corp FX8RP7NUSQNF008	Black	30 mm	0 °C	60 °C	26 dB	0.75 dB	50/125	Multimode OM3	3 mm	0.12 in	LC			MPO	8 ft	2.4 m
Panduit Corp FX8RP7NQSVNF016
Panduit Corp FX8RP7NUSQNF085	Black	30 mm	0 °C	60 °C	26 dB	0.75 dB	50/125	Multimode OM3	3 mm	0.12 in	LC	25.9 m	85 ft	MPO
Panduit Corp FX8RP7NUSQNF071	Black	30 mm	0 °C	60 °C	26 dB	0.75 dB	50/125	Multimode OM3	3 mm	0.12 in	LC	21.6 m	71 ft	MPO
Panduit Corp FX8RP7NUSQNF047	Black	30 mm	0 °C	60 °C	26 dB	0.75 dB	50/125	Multimode OM3	3 mm	0.12 in	LC	14.3 m	47 ft	MPO
Panduit Corp FX8RP7NUSQNF081
