1241 Series
Manufacturer: VersaLogic Corporation
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
SBC 1.8GHZ 1 CORE 2GB/0GB RAM
| Part | Contents | Watchdog Timer | Ethernet Speed Options | Ethernet Ports | Power (Watts) | Serial Interface Count | Supported Serial Standards | Storage Interface | Number of Storage Interfaces | Expansion Site/Bus | Cooling Type | Analog Input Count | Analog Output Count | Video Outputs | Digital I/O Lines | USB 2.0 Count | USB | RAM Installed | RAM Capacity | Operating Temperature (Max) | Operating Temperature (Min) | Number of Cores | Size / Dimension Length | Size / Dimension Width | Speed | Form Factor | Core Processor | USB 3.0 Count | Video Outputs (DP) Count | Ethernet Interface |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 VersaLogic Corporation | Keyboard Mouse | Yes | 100Mbps 10Mbps | 2 | 25 W | 4 | RS-232 RS-422 RS-485 | ATA-4 ATA100 CompactFlash SATA2 | 2 count | PC/104-Plus | Fan | 8 | 0 | LVDS VGA | 32 lines | 4 count | USB 2.0 | 0 GB | 2 GB | 60 °C | 0 °C | 1 | 5.75 in | 8 in | 1.8 GHz | EBX | Intel Pentium M 745 | |||
 VersaLogic Corporation | Keyboard Mouse | Yes | 1000Mbps 100Mbps 10Mbps | 2 | 15 W | 4 | RS-232 RS-422 RS-485 | mSATA SATA 3.0 | 2 count | I2C mPCIe PCIe SATA SPI/SPX | Heat Plate | 8 | 4 | DP LVDS | 24 lines | 4 count | USB 2.0 USB 3.0 | 8 GB | 8 GB | 60 °C | 0 °C | 2 | 3.74 in | 4.92 in | 2.3 GHz | COM Basic | Intel Core i3 | 2 count | 2 | |
 VersaLogic Corporation | Keyboard Mouse | Yes | 100Mbps 10Mbps | 2 | 6.3 W | 4 | RS-232 RS-422 RS-485 | microSD mPCIe mSATA SATA | microSD mPCIe PC/104-Plus SATA SPI | Heat Sink | LVDS VGA | 32 lines | 5 count | USB 2.0 | 2 GB | 2 GB | 85 °C | -40 °C | 1 | 5.75 in | 8 in | 800 MHz | EBX | Vortex86DX2 | ||||||
 VersaLogic Corporation | Keyboard Mouse | Yes | 1000Mbps 100Mbps 10Mbps | 8.4 W | microSD SATA 2.0 | 2 count | CANbus microSD PCIe SATA SMBus | Heat Sink | DDI LVDS VGA | 7 | USB 2.0 | 1 GB | 1 GB | 85 °C | -40 °C | 1 | 2.17 in | 3.31 in | 1.6 GHz | COM Express mini (Type 10) | Intel Atom E680T | |||||||||
 VersaLogic Corporation | Keyboard Mouse | Yes | 1000Mbps 100Mbps 10Mbps | 5.3 W | 2 | RS-232 RS-422 RS-485 | mSATA SATA 2.0 | I2C mPCIe PC/104-Plus SATA | Heat Sink | DP | 8 lines | 4 count | USB 2.0 | 0 GB | 8 GB | 85 °C | -40 °C | 2 | 4.23 in | 3.77 in | 1.33 GHz | PC/104 | Intel Atom E3825 | |||||||
 VersaLogic Corporation | Keyboard Mouse | Yes | 1000Mbps 100Mbps 10Mbps | 2.8 W | 1 | RS-232 RS-422 RS-485 | microSD mSATA SATA 2.0 | CANbus eMMC GPIO I2C microSD mPCIe SATA SPI UART | Heat Sink | HDMI LVDS | 8 lines | 2 count | USB 2.0 | 2 GB | 2 GB | 85 °C | -40 °C | 4 | 3.7 in | 4.9 in | 800 MHz | COM Basic | ARM Cortex-A9 i.MX6Quad | |||||||
 VersaLogic Corporation | Yes | 1000Mbps 100Mbps 10Mbps | 2 | 21.6 W | 4 | RS-232 RS-422 RS-485 | mSATA SATA 3.0 | 2 count | I2C mPCIe PCIe SATA SPI/SPX | Heat Plate | 8 | 4 | DP LVDS | 24 lines | 4 count | USB 2.0 USB 3.0 | 16 GB | 16 GB | 60 °C | 0 °C | 4 | 3.74 in | 4.92 in | 2.8 GHz | COM Basic | Intel Core i7 | 2 count | 2 | ||
 VersaLogic Corporation | Keyboard Mouse | Yes | 1000Mbps 100Mbps 10Mbps | 6.5 W | 4 | RS-232 RS-422 RS-485 | ATA100 IDE DOM | PC/104 SPX SUMIT | Heat Sink | LVDS | 2 count 3 count | USB 2.0 | 0 GB | 2 GB | 85 °C | -40 °C | 1 | 3.6 in | 3.8 in | 1.33 GHz | PC/104 | Intel Atom Z520PT | GbE | |||||||
VersaLogic Corporation | Keyboard Mouse | Yes | 100Mbps 10Mbps | 2 | 10 W | 4 | RS-232 RS-422 RS-485 | ATA100 SATA | 2 count | PC/104-Plus | 8 | 0 | DDI LVDS VGA | 32 lines | 6 count | USB 2.0 | 0 GB | 1 GB | 60 °C | 0 °C | 1 | 5.75 in | 8 in | 1.2 GHz | EBX | VIA Eden | ||||
 VersaLogic Corporation | Keyboard Mouse | Yes | 1000Mbps 100Mbps 10Mbps | 2 | 8.1 W | 4 | RS-232 RS-422 RS-485 | eMMC microSD mSATA SATA 3.0 | I2C microSD mPCIe SATA | Heat Plate | DP LVDS | 8 lines | USB 2.0 (4) USB 3.0 | 2 GB | 2 GB | 85 °C | -40 °C | 2 | 3.74 in | 3.74 in | 1.3 GHz 1.8 GHz | COM Compact | Intel Atom E3930 |
