095001 Series
Manufacturer: Molex
Beta
⌘K
CONN MOD JACK 8P8C R/A UNSHLD
| Part | Connector Type | Tab Direction | Operating Temperature [Min] | Operating Temperature [Max] | Ratings | LED Color | Features | Orientation | Number of Positions/Contacts | Shielding | Contact Finish | Number of Rows | Termination | Contact Material | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Ports |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | Board Lock Keyed | 90 ° | 8p8c (RJ45 Ethernet) | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Through Hole | 50 µin | 1.27 µm | 1 |
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 6p6c (RJ11 RJ12 RJ14 RJ25) | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Through Hole | 50 µin | 1.27 µm | 1 | |
Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 6p4c | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Surface Mount | 50 µin | 1.27 µm | 1 | |
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 6p4c | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Through Hole | 50 µin | 1.27 µm | 1 | |
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 4p4c | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Through Hole | 50 µin | 1.27 µm | 1 | |
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 4p4c | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Surface Mount | 50 µin | 1.27 µm | 1 | |
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 8p8c (RJ45 Ethernet) | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Surface Mount | 50 µin | 1.27 µm | 1 | |
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 8p8c (RJ45 Ethernet) | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Through Hole | 50 µin | 1.27 µm | 1 | |
 Molex | Jack | Down | -40 °C | 80 C | Cat3 | Does Not Contain LED | 90 ° | 6p6c (RJ11 RJ12 RJ14 RJ25) | Unshielded | Gold | 1 | Solder | Phosphor Bronze | Surface Mount | 50 µin | 1.27 µm | 1 |
