CS00096 Series
Manufacturer: SiTime
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
32.770KHZ, 20PPM,1P5X0P8 WCSP TR
| Part | Frequency Stability | Size / Dimension Width | Size / Dimension Length | Package Length | Package Name | Package Width | Voltage - Supply | Mounting Type | Frequency | Package / Case | Output | Height - Seated (Max) | Base Resonator | Operating Temperature (Max) | Operating Temperature (Min) | Type | Current - Supply (Max) | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
20 ppm | 0.033 in | 0.061 in | 1.54 mm | 4-CSP | 0.84 mm | 1.8 V | Surface Mount | 32.7707 kHz | 4-UFBGA CSPBGA | LVCMOS | 0.024 in | MEMS | 70 °C | -20 °C | TCXO | 4.5 µA | ||
20 ppm | 0.033 in | 0.061 in | 1.54 mm | 4-CSP | 0.84 mm | 1.8 V | Surface Mount | 32.7707 MHz 32.7707 kHz | 4-UFBGA CSPBGA | LVCMOS | 0.024 in | MEMS | 70 °C | -20 °C | TCXO | 4.5 µA | Disable Enable | |
20 ppm | 0.033 in | 0.061 in | 1.54 mm | 4-CSP | 0.84 mm | 1.8 V | Surface Mount | 32.7707 kHz | 4-UFBGA CSPBGA | LVCMOS | 0.024 in | MEMS | 70 °C | -20 °C | TCXO | 4.5 µA |
