Nch 60V 2A Middle Power MOSFET
Description
AI
RV7L020GN is low on-resistance MOSFET for Switching and Load switch.
Beta
⌘K
Nch 60V 2A Middle Power MOSFET
Nch 60V 2A Middle Power MOSFET
| Part | Drive Voltage (Max Rds On, Min Rds On) | Current - Continuous Drain (Id) @ 25°C | Gate Charge (Qg) (Max) @ Vgs | Drain to Source Voltage (Vdss) | Mounting Type | Rds On (Max) @ Id, Vgs | FET Type | Input Capacitance (Ciss) (Max) @ Vds | Technology | Package / Case | Vgs(th) (Max) @ Id | Operating Temperature | Power Dissipation (Max) | Vgs (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 4.5 V 10 V | 2 A | 2.1 nC | 60 V | Surface Mount | 157 mOhm | N-Channel | 110 pF | MOSFET (Metal Oxide) | 3-XDFN | 2.7 V | 150 °C | 1.1 W | 20 V |
