E2E-C03 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCT 0.8MM CYLIND
| Part | Sensor Type | Termination Style | Voltage - Supply [Min] | Voltage - Supply [Max] | Shielding | Material - Body | Operating Temperature [Min] | Operating Temperature [Max] | Indicator | Response Frequency | Output Type | Output Type | Sensing Distance | Sensing Distance | Ingress Protection | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | Inductive | Cable Leads | 10 VDC | 30 VDC | Shielded | Stainless Steel | -25 °C | 70 °C | LED | 5 kHz | 3 | PNP-NC | 0.032 " | 0.8 mm | IP67 | Cylinder |
Omron Automation and Safety | Inductive | Cable with Connector | 10 VDC | 30 VDC | Shielded | Stainless Steel | -25 °C | 70 °C | LED | 5 kHz | 3-Wire NPN-NC | 0.032 " | 0.8 mm | IP67 | Cylinder | |
 Omron Automation and Safety | Inductive | Cable Leads | 10 VDC | 30 VDC | Shielded | Stainless Steel | -25 °C | 70 °C | LED | 5 kHz | 3-Wire NPN-NO | 0.032 " | 0.8 mm | IP67 | Cylinder | |
Omron Automation and Safety | Inductive | Cable Leads | 10 VDC | 30 VDC | Shielded | Stainless Steel | -25 °C | 70 °C | LED | 5 kHz | 3 | PNP-NO | 0.032 " | 0.8 mm | IP67 | Cylinder |
Omron Automation and Safety | Inductive | Cable Leads | 10 VDC | 30 VDC | Shielded | Stainless Steel | -25 °C | 70 °C | LED | 5 kHz | 3 | PNP-NO | 0.032 " | 0.8 mm | IP67 | Cylinder |
Omron Automation and Safety | Inductive | Cable with Connector | 10 VDC | 30 VDC | Unshielded | Stainless Steel | -25 °C | 70 °C | LED | 3.5 kHz | 3-Wire NPN-NO | 0.079 in | 2 mm | IP67 | Cylinder | |
 Omron Automation and Safety | Inductive | Cable Leads | 10 VDC | 30 VDC | Unshielded | Stainless Steel | -25 °C | 70 °C | LED | 3.5 kHz | 3 | PNP-NO | 0.079 in | 2 mm | IP67 | Cylinder |
Omron Automation and Safety | Inductive | Cable with Connector | 10 VDC | 30 VDC | Unshielded | Stainless Steel | -25 °C | 70 °C | LED | 3.5 kHz | 3-Wire NPN-NC | 0.079 in | 2 mm | IP67 | Cylinder | |
Omron Automation and Safety | Inductive | Cable Leads | 10 VDC | 30 VDC | Unshielded | Stainless Steel | -25 °C | 70 °C | LED | 3.5 kHz | 3-Wire NPN-NC | 0.079 in | 2 mm | IP67 | Cylinder | |
Omron Automation and Safety | Inductive | Cable Leads | 10 VDC | 30 VDC | Shielded | Stainless Steel | -25 °C | 70 °C | LED | 5 kHz | 3-Wire NPN-NC | 0.032 " | 0.8 mm | IP67 | Cylinder |
