895-065 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 65POS 0.100
| Part | Contact Type | Material - Insulation | Mounting Type | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Contact Material | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Gender | Number of Rows | Color | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Number of Positions | Card Type | Termination Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | 1 | Black | Wire Wrap | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 |
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | Female | 1 | Black | Solder | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 |
EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | Female | 1 | Black | Wire Wrap | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 | |
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | Female | 1 | Black | Solder | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 | ||
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | 1 | Black | Solder | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 |
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Female | 1 | Black | Solder | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 |
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Female | 1 | Black | Solder | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 |
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | Female | 1 | Black | Solder | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 | |
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Female | 1 | Black | Wire Wrap | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 |
 EDAC Inc. | Cantilever | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Copper Alloy | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | 1 | Black | Solder | 125 °C | -40 C | Single | 65 | Non Specified - Single Edge | 1 |
