6456 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTI-PAIR 6COND 22AWG BLACK
| Part | Shield Material | Shield Coverage | Conductor Strand [custom] | Conductor Strand [custom] | Wire Gauge | Cable Type | Operating Temperature [Min] | Operating Temperature [Max] | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Features | Number of Conductors | Length | Length | Shield Type | Jacket (Insulation) Material | Voltage | Conductor Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Aluminum Copper Tinned | 65 % 100 % | 30 AWG | 7 | 22 AWG | Multi-Pair | -20 ░C | 60 °C | Black | 0.414 " | 10.52 mm | Drain Wire | 6 | 304.8 m | 1000 ft | Braid Foil | Poly-Vinyl Chloride (PVC) | 300 VDC | Copper Tinned | 0.053 " | 1.346 mm | High Density Polyethylene (HDPE) |
