PJ-12V100 Series
Manufacturer: Delta Electronics
Beta
⌘K
AC/DC CONVERTER 12V 100W
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Approval Agency | Voltage - Isolation | Voltage - Output 1 | Type | Number of Outputs | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Features | Applications | Mounting Type | Power (Watts) | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | 70 °C | -10 °C | CB CE cURus TUV | 3000 V | 12 V | Open Frame Conformal Coated | 1 | 33 mm | 2.44 " | 6.1 " | 1.3 in | 155 mm | 62 mm | Adjustable Output PFC Universal Input | ITE (Commercial) | Chassis Mount | 100 W | 87.5 % |
 Delta Electronics | 70 °C | -10 °C | CB CE cURus TUV | 3000 V | 12 V | Open Frame | 1 | 33 mm | 2.44 " | 6.1 " | 1.3 in | 155 mm | 62 mm | Adjustable Output PFC Remote On/Off Universal Input | ITE (Commercial) | Chassis Mount | 100 W | 87.5 % |
 Delta Electronics | 70 °C | -10 °C | CB CE cURus TUV | 3000 V | 12 V | Enclosed | 1 | 45 mm | 2.83 " | 7.28 in | 1.65 " | 185 mm | 72 mm | Adjustable Output PFC Remote On/Off Universal Input | ITE (Commercial) | Chassis Mount | 100 W | 87.5 % |
