6136.0138 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
PWR ENT MOD RCPT IEC320-C20 PNL
| Part | Termination | Termination | Termination | Switch Features | Ingress Protection | Voltage Rating - Appliance Inlet | Filter Type | Mounting Type | Connector Type | Approval Agency | Material Flammability Rating | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Current Rating - Appliance Inlet | Panel Thickness | Panel Thickness | Connector Style | Accomodates a Fuse |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 6.3 mm | Quick Connect | 0.25 " | Circuit Breaker Switch On-Off | IP40 | 250 VAC | Unfiltered - Commercial | Panel Mount Snap-In | Receptacle Male Blades - Module | CCC cULus ENEC | UL94 V-0 | 50.8 mm | 43.2 mm | 16 A | 0.098 in | 2.5 mm | IEC 320-C20 | |
 SCHURTER Inc. | 6.3 mm | Quick Connect | 0.25 " | Circuit Breaker Switch On-Off | IP40 | 250 VAC | Unfiltered - Commercial | Panel Mount Snap-In | Receptacle Male Blades - Module | CCC cULus ENEC | UL94 V-0 | 50.8 mm | 43.2 mm | 16 A | 0.059 in | 1.5 mm | IEC 320-C20 |
