103327 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER VERT 6POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Material	Number of Positions Loaded	Termination	Mounting Type	Insulation Material	Number of Positions	Pitch - Mating	Pitch - Mating	Shrouding	Contact Shape	Fastening Type	Insulation Height [z]	Insulation Height [z]	Contact Type	Material Flammability Rating	Overall Contact Length	Overall Contact Length	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Mating	Contact Length - Post	Contact Length - Post	Connector Type	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Style	Current Rating (Amps)	Insulation Color	Number of Rows	Number of Positions [custom]
TE Connectivity AMP Connectors 4-103327-0-06	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	6	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 1-103327-4	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	14	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 4-103327-0-03	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic		0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 4-103327-0-28	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	28	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 4-103327-0-05	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	5	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 4-103327-0-29	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	29	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 4-103327-0-31	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic		0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1	31
TE Connectivity AMP Connectors 4-103327-0-25	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	25	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 4-103327-0-09	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	9	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
TE Connectivity AMP Connectors 4-103327-0-08	2.54 µm	100 µin	Copper Alloy	All	Solder	Through Hole	Thermoplastic	8	0.1 "	2.54 mm	Unshrouded	Square	Push-Pull	0.09 in	2.29 mm	Male Pin	UL94 V-0	11.18 mm	0.44 in	105 ░C	-65 ░C	100 çin	2.54 çm	Tin-Lead	3.05 mm	0.12 in	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Board to Board Cable	3 A	Black	1
